INSTRUCTIONS FOR COIN TRIP SWITCH ADJUSTMENT
WIRE SHOULD BE IN CONTACT
WIT.,. END OF CRESCENT
OPENING
WHEN BLADE
ADJUSTMENT IS MADE.
- NYLON SWITCH ACTUATOR
Long blade should be in contact with nylon switch actuator and have
0
maximum
ave rtraveI of
I
/32.
or
Using a gram gauge, tension of long blade should not exceed 10 grams.
SWITCH ADJUSTMENT
1. For small coins, such as dimes, adjust short blade so that the 'gap'
between the
silver contacts is .045 to .055.
2. For larger
&
heavier coins the 'gap' should be .045 to .060.
3. Do not adjust 'gap'
closer than .040.
POWER TRA.NSFORMER:
LOCATED ON MECHANISM PANEL, IT IS EQUIPPED WITH A SECONDARY
TAP.
IF YOUR GAME
IS
ON
LOCATION
WITH EXTREMELY LOW LINE
VOLT-
AGE, REMOVE
LEAD
FROM LUG MARKED
24
VOLTS AND SOLDER TO ALTER-
NATE LUG MARKED "HIGH". THIS WILL BOOST SECONDARY VOLTAGE
APPROXIMATELY 2-) VOLTS.
LEG
LEVELERS:
ARE
PROVIDED FOR
TWO
PURPOSES - 1ST
TO
LEVEL
GAME ON
LOCATION,
2ND TO INCRF,ASE PITCH FOR GAME PERCENTAGING.
IF IT IS DES IRED
TO
SPEED UP
PLAY
AND DECREASE SCORES, RAISE REAR LEG
LEVELERS
TO
INCREASE
PITCH.
3
