J119-1 Red-Green, +50V to Lower Right Flipper Coil
J 119-2 Red-Green, Loop End from J 119-1
J119-3 Key.
J119-4 Red-Blue, +50V to Lower Left Flipper
J 119-5 Red-Blue, Loop End from J 119-4
J119-S Red-Violet, +50V to Playfield Coil
J 119-7 Red-Violet, Loop End from J 119-S
J119-S Red-Gray, +50V to Playfield Coil
J119-9 Red-Gray, Loop End from J119-8
J120-1 Orange-Gray, Holding, Playfield Coil
J120-2 Not Used
J12Q-3 Yellow-Gray, Power, Playfield Coil
J120-4 Orange-Violet, Holding, Playfield Coil
J12Q-5 Not Used
J120-S Yellow-Violet, Playfield Coil
J 120-7 Orange-Blue, Holding, Lower Left Flipper Coil
J 120-S Not Used
J120-9 Yellow-Blue, Power, Lower Left Flipper Coil
J120-10 Key
J 120-11 Orange-Green, Holding, Lwr Right Flipper Coil
J120-12 Not Used
J120-13 Yellow-Green, Power, Lower Right Flipper Coil
J12,., Yellow-Brown, Lamp Col. 1 to Playfield
J121-2 Yellow-Red, Lamp Col. 2 to Playfield
J121-3 Yellow-Orange, Lamp Col. 3 to PJayfield
J121-4 Yellow-Black, Lamp Col. 4 to Playfield
J121-5 Yellow-Green, Lamp Col. 5 to Playfield
J121-S Yellow-Blue, Lamp Col. S to Playfield
J121-7 Not Used
J121-S Key
J121-9 Yellow-Gray, Lamp Col. 8 to Playfield
J122-1 Key
J 122-2 Not Used
J122-3 Yellow-Gray, Lamp ColS to Coin Door Bd. J3-9
J 123-1 Not Used
J123-2 Not Used
J 123-3 Not Used
J 123-4 Not Used
J 123-5 Not Used
J123-S Yellow-Blue to Insert Lamps
J123-7 Yellow-Violet to Insert lamps
J123-8 Key
J123-9 Yellow-Gray to Insert Lamps
J 124 -1 Red-Brown, Lamp Row 1 to Playfield
J124 -2 Red-Black, Lamp Row 2 to Playfield
J124 -3 Key
J124 -4 Red-Orange, Lamp Row 3 to Playfield
J124 -5 Red-Yellow, Lamp Row 4 to Playfield
J124 -S Red-Green, Lamp Row 5 to Playfield
J 124 -7 Red-Blue, Lamp Row S to Playfield
J124 -8 Red-Violet, Lamp Row 7 to Playfield
J124 -9 Red-Gray, Lamp Row S to Playfield
J125-1 Not Used
J 125-2 Not Used
J125-3 Key
J125-4 Not Used
J125-5 Not Used
J 125-S Not Used
J125-7 Red-Blue, Lamp Row S to Coin Door Bd. J3-10
J 125-S Red-Violet, Lamp Row 7 to CoIn Door Bd. J3-11
J125-9 Red-Gray, Lamp Row 8 to Coin Door Bd. J3-12
J 126-1 Red-Brown, Lamp Row 1 to Insert
J126-2 Red-Black, Lamp Row 2 to Insert
J12S-3 Key
J126-4 Red-Orange, Lamp Row 3 to Insert
J12S-5 Red-Yellow, Lamp Row 4 to Insert
J126-S Red-Green, Lamp Row 5 to Insert
J 126-7 Red-Blue, Lamp Row S to Insert
J126-8 Red-Violet, Lamp Row 7 to Insert
J12S-9 Red-Gray, Lamp Row S to Insert
J127-1 White-Green, 9.SVAC from Xformer Secondary
J127-2 White-Green, 9.8VAC Loop End from J127-1
J127-3 White-Green, 9.SVAC from Xformer Secondary
J127-4 Key
J127-5 White-Green, 9.8VAC Loop End from J127·3
J128-1 White-Red, 1SVAC Loop End from J128-2
J128-2 White-Red, 1SVAC from Xformer Secondary
J128-3 White-Red, 1SYAC Loop End from J12S-4
J128-4 White-Red, 1SVAC from Xformer Secondary
J12S-5 Black-YellOW, 1SVAC Loop End from J128-6
J 128-S Black· Yellow, 1SVAC from Xformer Secondary
J128-7 Key
J128-8 Black-Yellow, 1SVAC Loop End from J128-9
J128-9 Black-Yellow, 1SVAC from Xformer Secondary
J 129-1 Red, 9VAC from Xformer Secondary
J 129·2 Red, 9VAC from Xformer Secondary
J129-3 Key
J129-4 Blue-White, 13VAC from Xformer Secondary
J129-5 Blue-White, 13VAC Loop End from J129-4
J129-S Blue-White, 13YAC from Xformer Secondary
J129-7 Blue-White, 13VAC Loop End from J129-6
J 130 Not Used
J131 Not Used
J132 Not Used
J 133-1 Not Used
J 133-2 Red-Brown, +50V to Playfleld Coils
J133-3 Red-Black, +50V to Playfield Coils
J133-4 Key
J 133-5 Not Used
J133-S Red·White, +20V to PJayfield Flashlamps
3-23
