J10H Gray-Green, +12V to J21Q-7. J606-7
J101-2 Gray-Green, +12V to J21Q-6, J606-6
J101-3 Gray, +SV to J21Q-S, J606-S
J101-4 Gray, +SV to J21Q-4, J606-4
J101-S Black, Ground to J21Q-3, J606-3
J101-6 Key
J101-7 Black, Ground to J210-1, J606-1
J102 34-Pin Ribbon Cable, Data toffrom CPU J211
J104-1 White-Violet, 6.8VAC G.I. to Coin Door Bd. J2-3
J104-2 Key
J104-3 Violet, Return, G.I. to Coin Door Bd. J2-S
J10S-1 Brown, Return, G.I. to Coin Door Board J2-S
J105-2 Orange, Return, G.I. to Playfield
J10S-3 Yellow, Return, G.I. to Playfield
J10S-4 Key
J10S-S Not Used
J10S-6 Not Used
J105-7 White-Brown, 6.8VAC, G.I. to Coin Door Bd. J2-3
J10S-8 White-Orange, 6.8VAC, G.I. to Playfield
J105-9 White-Yellow, 6.8VAC, G.I. to Playfield
J105-10 Not Used
J105-11 Not Used
J106-1 Not Used
J 106-2 Not Used
J106-3 Not Used
J106-4 Key
J106-S Green, Return G.I. to Insert Panel
J106-6 Violet, Return G.t. to Insert Panel
J106-7 Not Used
J106-8 Not Used
J106-9 Not Used
J106-10 White-Green, 6.8VAC, G.I. to Insert Panel
J106-11 White-Violet, 6.8VAC, G.I. to Insert Panel
J107-1 Not Used
J107-2 Key
J107-3 Blue-Red to Insert Flasher
J107-4 Not Used
J107-S Not Used
J 108 Not Used
J109-1 Blue-Brown, Solenoid 2S to Playfield Coil
J 109-2 Blue-Red, Solenoid 26 to Playfield Flasher
J 109-3 Blue-Orange, Solenoid 27 to Playfield Flasher
J109-4 Blue-Yellow, Solenoid 28 to Playfield Flasher
J 109-S Red-Brown Tieback Diode
J109-6 Not Used
J109-7 Key
J 109-8 Not Used
J 109-9 Not Used
J110-1 Brown-White to Solenoid 37 to Playfield
J110-2 Key
J 110-3 Orange-White to Solenoid 38 to Playfield
J110-4 Yellow-White to Solenoid 39 to Insert
J11Q-S Green-White to Solenoid 40 to Insert
J111-1 Bla9k-Brown, Solenoid 17 to Playfield Flasher
J111-2 Black-Red, Solenoid 18 to Playfield Flasher
J 111-3 Black-Orange, Solenoid 19 to Playfield Flasher
. J111-4 Black-Yellow, Solenoid 20 to Playfield Coil
J111-5 Not Used
J 111-6 Blue-Black, Solenoid 22 to Playfl8ld Flasher
J 111-7 Blue-Violet, Solenoid 23 to Playfield Flasher
J111-8 Blue-Gray, Solenoid 24 to Playfield Flasher
J111-9 Key
J111-10 Not Used
J111-11 Not Used
J111-12 Not Used
J111-13 Not Used
J 112-1 Black-Brown to Insert Flasher
J112-2 Black-Red to Insert Flasher
J112-3 Black-Orange to Insert Flasher
J112-4 Key
J112-S Blue-Green to Insert Flasher
J 112-6 Not Used
J112-7 Not Used
J112-8 Not Used
J 112-9 Not Used
J113-1 Brown-Black, Solenoid 9 Drive to Playfield Coil
J113-2 Key
J113-3 Brown-Red, Solenoid 10 to Playfield Coli
J113-4 Brown-Orange, Solenoid 11 to Playfield Coil
J 113-5 Brown-Yellow, Solenoid 12 to Playfield Coil
J113-6 Brown-Green, Solenoid 13 to Playfield Coil
J113-7 Brown-Blue, Solenoid 14 to Playfield Coil
J113-8 Brown-Violet, Solenoid 1S to Playfield Coil
J113-9 Brown-Gray, Solenoid 16 to Playfield Coil
J114 Not Used
J11S Not Used
J116-1 Violet-Brown, Solenoid 1 to Playfield Coil
J116-2 ViOlet-Red, Solenoid 2 to Playfield Coil
J116-3 Key
J 116-4 Violet-Orange, Solenoid 3 to Playfield Coil
J116-S Violet-Yellow, Solenoid 4 to Playfield Coil
J116-6 ViOlet-Green, Solenoid 5 to Playfield Coil
J116-7 Violet-Blue, Solenoid 6 to Playfield Coil
J 116-8 Violet-Black, Solenoid 7 to Backbox Coil
J116-9 Violet-Gray, Solenoid 8 to Playfield Coil
J117 Not Used
J118 Not Used
3-22
