Game Operation
II
WARNING
II
After assembly and installation at its site location. this game must be plugged into a
properly grounded outlet to prevent shock hazard, and to assure proper game
operation. DO NOT use a 'cheater' plug to defeat the ground pin on the line cord.
DO NOT cut off the ground pin.
POWERING UP
With the coin door closed. plug the game in. and switch it ON. using the On-
Off switch. In normal operation. the player 1 score display initially shows
00. Then. the game goes into the Attract Mode (playfield and backbox lamps
flashing. sounds being heard. etc .. if the operator does not change the
Factory Setting).
Open the coin door and press the AurO-UP/MANUAL-DOWN switch to
MANUAL-DOWN. Press the ADVANCEbutton to begin the game test
routine. Retum to AurO-UP and perform the entire test to verify that the
game is operating satisfactorily.
NOTE
The SYSTEM 11C game program has a great capability to aid the operator and
service personnel: At game Tum-On (and also at the beginning of the
Test/Diagnostic Procedures). the player score displays now signal with a message.
"Press ADVANCEfor Report". that the game program has detected a possible
problem with the game. Usually. this report indicates that at least one switch has
NOT been actuated during ball play for 90 balls (approximately 30 games).
However. the game program compensates the game play requirements affected by
each disabled switch to allow 'nearly normal' play. This helps keep
RADICALI
earning good profitsl More information is available in the Test/Diagnostic
Procedures text describing the Switch Testing.
ATTRACT MODE*
Playfield and backbox lamps blink. The player score displays exhibit a
series of messages informing the player concerning:
A. Recent highest scores":
B. A "custom message";
("UVE TO SKATE. SKATETO UVE. STARTTHRASHIN.")*;
C. The score to achieve to obtain a
Replay award*;
These (or similar) displays reappear occasionally. accompanied by sounds
and music. until a player initiates game play by inserting a coin or. when
credits are available. pressing the Start button.
*-operator -adjustable feature
Game Operation
1-7
