WARNING
II
4. Raise the hinged backbox upright and stabilize it into position. Unlock the
backbox, and remove the backbox glass. storing it carefully to avoid scratches.
Remove the shipping block holding the Insert Board. This allows access to the
bolt holes used for securtng the backbox upright. Install the mounting bolts
(locaterd in printed envelope). through the bottom holes of the backbox into the
cabinet to secure the backbox. Close and latch the Insert Board. and install the
backbox glass. and lock the backbox.
NEVER
transport a pinball game with hinged backbox erect.
ALWAYS
lower the
backbox forward onto the playfteld cabinet on a layer of protective material to
prevent marring or damage and possible personal injury.
5. Extend each leg leveller slightly below the leg bottom. so that all four foot pads
are extended about the same distance.
Remove the cabinet from its support
and place it on the floor.
6. Adjust the leg levellers for proper playfteld level (side-to-side) and playfteld pitch
angle (incline) of approximately 7 degrees. (Again. it is recommended that these
measurements be made ON the playfteld, not the cabinet nor the playfteld cover
glass.) Tighten the nut on each leg leveller shaft to maintain this setting. as
shown in Figure 3.
CAUTION
Playing pitch angle adjustments can affect the operation of the plumb bob
tilt. inside the cabinet. The plumb bob weight is among the parts in the cash
box; the operator should install the weight and adjust the tilt mechanism
for proper operation. after completion of the desired playfield pitch angle
setting.
7. Move the game into the desired location; recheck the level and pitch angle of the
playfteld.
1-6 Pinball Assembly Instructions
8. Verify that the required number of balls are inside the game.
RADICALI
uses
two balls.
9. Clean and re-install the playfteld cover glass. Prepare the game for player
operation.
