485
MASTER DISPLAY
PLAYER DISPLAYS
(con't)
Pin Wire Color
Function
Pin Wire Color
Function
4PS - MASTER DISPLAY STROBE INPUTS
SP2 - PLAYER #2 SLAVE DISPLAY
I
N/C
Not Used
I
Blue
f
2 Brown-Gray
Strobe# 8
2 Violet
g
3 Brown- Violet
Strobe# 7
3 Red-Blue
100,000's
4 Violet-Gray
Strobe
e
lf
4 Green
e
5 Violet-Black
Strobe e l S
5 Yellow
d
6 Brown-Black
Strobe# 1
6 Red-Green
10,000's
7 Brown-Red
Strobe e 2
7 Red- Yellow
1,000's
8 Brown-Orange
Strobes
3
8
N/C
Not Used
9
Brown- Yellow Strobe# 4
9
Brown- White
Anode Keep Alive
10 Brown-Green
Strobe# 5
10 White-Black
Cathode Keep Alive
11 Brown-Blue
Strobe# 6
11 Red-Orange
100's
12 Violet-Red
Strobe s l O
12 Red-Brown
lO's
13 Violet-Orange
Strobe
e
l l
13
N/C
Key
14 Violet-Blue
Strobe#14
14 Orange
c
15 Violet-Brown
Strobe#
9
15 Red-Black
Units
16 Violet-Green
Strobe# 13
16 Red
b
17 Violet- Yellow
Strobe.e l Z
17 Brown
a
18
N/C
Not Used
18
N/C
Not Used
4P6 - MASTER DISPLAY BCD INPUTS
SP3 - PLAYER #3 SLAVE DISPLAY
1
Blue-Red
Bl
1 Blue
f
2
Blue-Orange
Cl
2 Violet
g
3
Blue-White
Blanking
3 Orange- Violet
100,000's
4
Blue- Yellow
01
4 Green
e
5
Blue-Brown
Al
5 Yellow
d
6
Blue-Black
B2
6 Orange-Blue
10,000's
7
Blue- Violet
C2
7 Orange-Green
1,000's
8
Blue-Gray
02
8
N/C
Not Used
9
Blue-Green
A2
9
Brown-White
Anode Keep Alive
10 White-Black
Cathode Keep Alive
4P7 - MASTER DISPLAY POWER INPUTS
11 Orange- Yellow 100's
1
White-Black
Keep Alive -100 VOC
12 Orange-Red
10's
2
Brown
+ 100 VDC
13
N/C
Key
3
Gray
Logic B+ (+5 VOC)
14 Orange
c
4
N/C
Not Used
15 Orange-Brown
Units
5
Black
Ground
16 Red
b
6
Orange
-100 VOC
17 Brown
a
18
N/C
Not Used
PLA YER DISPLAYS
SP4 - PLAYER #4 SLAVE DISPLAY
SPI - PLAYER #1 SLAVE DISPLAY
I
Blue
f
1 Blue
f
2 Violet
g
2 Violet
g
3 Yellow- Violet
100,000's
3 Brown-Blue
100,000's
4 Green
e
4 Green
e
5 Yellow
d
5 Yellow
d
6 Yellow-Blue
10,000's
6 Brown-Green
1O,000's
7 Yellow-Green
1,000's
7 Brown- Yellow 1,000's
8
N/C
Not Used
8
N/C
Not Used
9
Brown- White
Anode Keep Alive
9
Brown -Wh ite
Anode Keep Alive
10 White-Black
Cathode Keep Alive
10 White-Black
Cathode Keep Alive
11 Yellow-Orange
100's
11 Brown-Orange
100's
12 Yellow-Red
10's
12 Brown-Red
lO's
13
N/C
Key
13
N/C
Key
14 Orange
c
14 Orange
c
15 Yellow-Brown
Units
15 Brown-Black
Units
16 Red
b
16 Red
b
17 Brown
a
e
17 Brown
a
18
N/C
Not Used
18
N/C
Not Used
32
