A-22422 Monster Mech. Assembly
Item Part Number
Description
1
A-22404
Motor & Gearbox Assembly
a) 14-8015
Motor
b) 03-9222
Pinion Gear
c) 03-9219
Gear Cluster (3)
d) 03-9219-2
Gear Cluster
e) 20-10131-07Y Metric Screw: M2.6 x 8" (2)
f) 02-5450
Standoff (3)
g) 02-5444
Shaft
h) 02-5443
Drive Shaft
j)
20-8712-12
E-Ring, 1/8" Shaft (4)
k) 4700-00004-00 Flat Washer: 9/64 x 3/8 x 21 gao
m) 4008-01168-04 Mach. Screw: 8-32 x
1A
Hex
Head w/ SEMS (3)
n) 04-11168
Motor Mounting Bracket
p) 04-11183
Faceplate
q) 03-9873
Spacer
2
04-11189.1
Monster Mech. Bracket
3
04-11188
Monster Mech. Crank
4
01-14964
Monster Mech. Link
5
01-8600
Insulator (4)
6
01-8240
Nut Plate 2-56
7
4408-01119-01 Nut 8-32 ESNA
8
4008-01083-04 Set Screw: 8-32 x
1A"
9
5647-12693-11 Mini Micro Switch
10
5070-09054-00 Diode 1N4004 i.OA.
11
4002-01105-10 Mach. Screw 2-56 x 5/8"
12
20-8712-18
E-Ring 3/16" Shaft
13
H-22008-8
Cable 8"
14
H-22420
Frank Switch Cable
15
03-9454
Cable Tie 4" Long .1 Wide
2-30
