A-21712-2
Up Down Post Assembly
This assembly is used in games
produced
before July
21, 1997.
A-21712-5
Up Down Post Assembly
This assembly is used in games
produced
after July
21, 1997.
9
Item Part Number
Description
Item Part Number
Description
1 01-12441
Diverter Post Bracket
1 01-12441
Diverter Post Bracket
2 03-7067-5
Coil Tubing
2 03-7067-5
Coil Tubing
3 01-8-508-T
Coil Retainer Bracket
3 01-8-508-T
Coil Retainer Bracket
4 AE-27-1200
Coil Assembly
4 AE-27-1200
Coil Assembly
5 10-135
Spring
5 10-135
Spring
6 04-10772
Armature Assembly, Tower
6 04-10996
Armature Assembly, Tower
7 23-6420
Rubber Grommet
7 23-6420
Rubber Grommet
8 4008-01 017 -04 Mach. Screw, 8-32 x 14"
8 4008-01 017-04 Mach. Screw, 8-32 x 14"
9 H-19523
Mini Solenoid Cable
9 H-19523
Mini Solenoid Cable
2-23
