A-17796-1
Ball Gate Actuator Assembly
Item Part Number
Description
1
2
3
4
5
6
7
01-12348
A-14406
A-11146
A-6892
10-120
4701-00003-00
4700-00089-00
8
9
10
4008-01021-07
10-194
H-19523-1
Ball Gate Coil Bracket
Coil Assembly
Armature Assembly
Frame
&
Eyelet Assy.
Spring
Lockwasher #18 Split
Flat Washer:
11/64 x 7/16 x 16ga.
Mach. Screw, 8-32 x 7/16"
Extension Spring
Cable
2-22
