POWER DRIVER BOARD CONTINUED ...
J115-1 Yellow-White, 6.8VAC from transformer secondary
J115-2 White-Brown, 6.8VAC from transformer secondary
J115-3 White-Brown, loop from J11S-2
J11S-4 White-Orange,
6.8VAC from transformer secondary
J115-5 White-Yellow, loop from J11S-6
J115-6 White-Yellow, 6.8VAC from transformer secondary
J11S-7 Orange, 6.8VAC from transformer secondary
J11S-8 Orange, 6.8VAC loop from J115-7
J11S-9 Key
J11S-10 Green, 6.8VAC from transformer secondary
J11S-11 Brown, 6.8VAC from transformer secondary
J11S-12 Brown, 6.8VAC loop from J11S-11
J116-1 Key
J116-2 Gray-Yellow, +12VDC to coin door; J2-4
J116-3 Black, Ground to coin door; J2-S
J 116-4 Not Used
J117-1 Key
J 117 -2 Gray-Yellow, +12VDC to J606-7
J117-3 Black, Ground to J606-3
J117 -4 Gray, +5VDC to J606-S
J118-1 Key
J118-2 Gray-Yellow, + 12VDC to playfield
J118-3 Black, Ground
J118-4 Not Used
J119-1 White-Violet, 6.8VAC G.I. to coin door; J2-2
J119-2 Key
J119-3 Violet, Return G.I. to coin door; J2-1
J120-1 Brown, Return G.I. to playfield
J120-2 Orange, Return G.I. to playfield
J120-3 Yellow, Return G.I. to playfield
J120-4 Key
J120-S Green, Return G.I. to playfield
J120-6 Violet, Return G.I. t.C'playfield
J120-7 White-Brown, 6.8V';C to playfield
J120-8 White-Orange,
6.8VAC to playfield
J120-9 White-Yellow, 6.8VAC to playfield
J120-10 White-Green, 6.8VAC to playfield
J120-11 White-Violet, 6.8VAC to playfield
J121-1 Brown, Return G.I. to insert
J121-2 Orange, Return G.I. to insert
J121-3 Yellow, Return G.I. to insert
J121-4 Key
J121-S Green, Return G.I. to insert
J121-6 Not Used
J121-7 White-Brown, 6.8VAC to insert
J121-8 White-Orange,
6.8VAC to insert
J121-9 White-Yellow, 6.8VAC to insert
J121-10 White-Green, 6.8VAC to insert
J121-11 Not Used
J122-1 Blue-Brown, 8012S to playfield flashlamps
J122-2 Blue-Red, 80126 to playfield flash lamps
J122-3 Blue-Orange, 80127 to playfield flashlamps
J122-4 Not Used
J122-S Not Used
J122-6 Not Used
J122-7 Key
J122-8 Not Used
J122-9 Not Used
J123 Not Used
J124-1 Blue-Brown, 80125 to insert flashlamps
J124-2 Blue-Red, 80126 to insert flash lamps
J124-3 Blue-Orange, 80127 to insert flashlamps
J124-4 Key
J124-S Blue-Yellow, 80128 to insert flashlamps
J12S-1 Black-Brown, 801 17 to insert flash lamps
J12S-2 Black-Red, 801 18 to insert flash lamps
J125-3 Black-Orange, 801 19 to insert flashlamps
J12S-4 Key
J125-5 Black-Yellow, 80120 to insert flashlamps
J125-6 Blue-Green, 80121 to insert flashlamps
J125-7 Blue-Black, 80122 to insert flashlamps
J125-8 Blue-Violet, 80123 to insert flashlamps
J125-9 Not Used
J126-1 Black-Brown, 801 17 to playfield flash lamps
J126-2 Black-Red, 801 18 to playfield flash lamps
J 126-3 Black-Orange, 801 19 to playfield flash lamps
J126-4 Black-Yellow, 80120 to playfield flash lamps
J126-5 Blue-Green, 80121 to playfield flash lamps
J126-6 Blue-Black, 801 22 to playfield flashlamps
J126-7 Blue-Violet, 80123 to playfield flashlamps
J126-8 Blue-Gray, 80124 to playfield flashlamps
J126-9 Key
J126-10 Not Used
J126-11 Not Used
J126-12 Not Used
J126-13 Not Used
J127-1 Brown-Black, 8019 to playfield coil
J127-2 Key
J127-3 Brown-Red, 80110 to playfield coil
J127-4 Brown-Orange, 801 11 to playfield coil
J127 -5 Not Used
J127-6 Brown-Green, 80113 to playfield coil
J127-7 Not Used
J127-8 Brown-Violet, 80115 to playfield coil
J127-9 Brown-Gray, 80116 to playfield coil
P.C, Board legend
J1·J6 Coin Door Interface Board
.Jtxx
Power Driver Board
J2xx CPU Board
J5xx Audio Board
,)6xx Dot Matrix Controller Board
J9xx Fliptronic II Board
Judge Dredd 3-28
