POWER DRIVER BOARD
A-12697-3
J101-1 Red, 9VAC from transformer secondary
J1 01-2 Red, 9VAC from transformer secondary
J1 01-3 Key
J1 01-4 Blue-White, 13VAC from transformer secondary
J1 01-5 Blue-White,
loop from J1 01-4
J1 01-6 Blue-White, 13VAC from transformer secondary
J101-7 Blue-White, loop from J101-6
J102-1 White-Red, loop from J102-2
J 102-2 White-Red, 16V AC from transformer secondary
J1 02-3 White-Red, loop from J1 02-4
J 102-4 White-Red, 16VAC from transformer secondary
J102-5 Black-Yellow, loop from J1 02-6
J 102-6 Black-Yellow, 16VAC from transformer secondary
J102-7 Key
J102-8 Black-Yellow, loop from J102-9
J1 02-9 Black-Yellow,16VAC from transformer secondary
J103 Not Used
J104 Not Used
J105-1 White-Blue, 50VAC to J901-1
J105-2 White-Blue, 50VAC to J901-3
J1 05-3 Key
J105-4 Not Used
J105-5 Not Used
J106-1 Not Used
J106-2 Not Used
J106-3 Not Used
J106-4 Key
J106-5 Red-White, +20V to insert flashlamps
J107-1 Not Used
J107-2 Violet-Orange, SOV to playfield coils
J107-3 Violet-Yellow, 50V to playfield coils
J107-4 Key
J107-5 Not Used
J107-6 Red-White, +20V to playfield flashlamps
J108 Not Used
J109 Not Used
J110 Not Used
J111 Not Used
J112-1 White-Green, 9.8VAC from transformer secondary
J112-2 White-Green, loop from J112-1
J112-3 White-Green, 9.8VAC from transformer secondary
J112-4 Key
J112-S White-Green, loop from J112-3
B
1·········1
1··.····1
1 4 1
9
1
7
J103 J102
J101
rn '"
•....
o
~
-:l
-
rn
"'
2l
~
-:l
-
rn
O>
o
~~
-:l
.
-
m '" ~
_-:l
J113
J114
J115
7
~1 121..••..•..... 11
com-
nn
,....
I]
,....
~m::':~m·:
.•••. a
,....
D
,....
a
,....
a
...,
II
v..., [] -e
~I:::::::::::::::::I~
J113 Ribbon Cable, Data to/from J211
J114-1 Gray/Green, +12VDC to J21 0-7
J 114-2 Not Used
J114-3 Gray, +5VDC to J21 0-5; J502-3
J 114-4 Not Used
J114-5 Not Used
J114-6 Key
J 114-7 Black, Ground to J21 0-1 ; J502-4; J904-4
P.C.
Board Legend
J1-J6 Coin Door Interface Board
J1xx Power Driver Board
J2xx CPU Board
J5xx Audio Board
J6xx Dot Matrix Controller Board
J9xx Fliptron ic " Board
Judge Dredd 3-27
