Left Ramp Assembly
pIn
0-12277
Part No.
A-12238
a) 5070-06258-00
b) 5647-12073-13
H-12370
01-8774
01-8795
01-8928
01-8929
03-8044-9
03-8197
07-6688-17N
07-6688-19N
23-6535
31-1471-2
31-1471-3
4002-01005-06
4106-01019-08
4700-00003-00
4701-00024-00
Description
Sub-Mini Switch Assy
Diode, 1N4001
Micro Switch
Ramp Switch Cable
Switch Bracket
Ramp Flap
Ramp Mounting Brkt.
Connecting Spring
Mini Post TR-Red
Ramp, Left
Rivet, 1/8 x 5/32, Nickel
Rivet, 1/8 x 7/32
Rubber Bumper
Decal - Left Ramp
Decal - Back Panel
Mach. Screw, 2-56 x 3/8
SM Screw, #6 x 1/2
Flat Washer,
1/8
x
9/32
x 21 gao
Lockwasher, #2 Split
Right Ramp Assembly
pIn
0-12276
Part No.
A-12238
a) 5070-06258-00
b) 5647-12073-13
H-12370
01-8774
01-8795
01-8928
01-9077
01-9014
03-8196
07-6688-17N
07-6688-19N
31-1471-1
31-1471-3
4002-01005-06
4700-00003-00
4701-00024-00
Center Ramp Assembly
pIn
0-12275
Part No.
Description
B-12156
H-12372
H-12373
H-12374
01-8966-L
01-8966-R
01-8972
03-6047-1
03-8149-12
03-8195
07-6688-21 N
4106-01004-12
4700-00003-00
Single Flash Lamp Assy
Flasher Cable
Cen/Rite Flash Cable
Center Flash Cable
Ball Deflector, L
Ball Deflector, R
Ramp Protector
Spacer,
1/4"
Mini Dome Insert T-ORG
Center Ramp
Rivet, 1/8 x 9/32
SM Screw, #6 x 3/4
Flat Washer,
1/8 x 9/32 x 21ga.
JOKERZ S8
Description
Sub-Mini Switch Assy
Diode, 1N4001
Micro Switch
Ramp Switch Cable
Switch Bracket
Ramp Flap
Ramp Mounting Brkt.
Connecting Spring
Ball Deflector Plate
Ramp, Right
Rivet, 1/8 x 5/32, Nickel
Rivet, 1/8 x 7/32
Decal - Right Ramp
Decal - Back Pane
Mach. Screw, 2-56 x 3/8
Flat Washer, 1/8 x
9/32
x 21 gao
Lockwasher, #2 Split
- --~~-
~ - - - - -
~
~~~-
-- -
.~ -
..
