Lamp Board ("3-C")
pin
C-12000
Part No.
5768-12245-00
24-8767
24-8768
5070-09054-00
5791·'0871-05
Descrl ption
PC
Board
Twist Lamp Socket
Bulb, #555 (6.3v, .25A)
Diode, 1N4004, 1.0A
Header, 5-pin sq post
Lamp Board ("16-cn)
pin
0·12221
Part No.
5768-12311 -00
24-8767
24-8768
5070-09054-00
5010·09534-00
Description
PC
Board
Twist Lamp Socket
Bulb, #555 (6.3v, .25A)
Diode, 1N4004, 1.0A
Resistor,
on
o
Kl
Motor Relay Board Assy
(Center Ramp Motor)
pin
C·11902·1
Part No.
5768-12221-00
5070-09054·00
5580-12145-00
5791-12273-02
5791-12273-07
Description
PC
Board
Diode, 1N4004, 1.0A
Relay, 24vdc, 30A
Header, 2-pin sq post (J1)
Header, 7 pin sq post (J2)
Lamp Board
("8-1")
pin
C-12098
Part No.
5768-12288-00
24-8804
24-8768
5070-09054-00
5791-10871-10
Description
PC Board
V-Wedge Lamp (#555) Skt.
Bulb, #555 (6.3v, .25A)
Diode, 1N4004, 1.0A
Header, 10-pin sq post
Lamp Board ("5-e
n
)
pin
C-12315
Part No.
5768-12334-00
24-8767
24-8768
5070-09054-00
5791-10871-07
Description
PC Board
Twist Lamp Socket
Bulb, #555 (6.3v, .25A)
Diode, 1N4004, 1.0A
Header, 7-pin sq post
0
-<ED-
0
Wl-c::=:r
WZ-c....J-
5580"()9SSS-
at
:D
r
<
o
o
CAT-:::-I
SS80-t214S"()O
(II (II
II II
v "
- N
VV
Relay Board
(Sol. 11 Gen. ilium)
pin
C-11998-1
Part No.
5768-12243-00
5070-09054-00
5580-09555-01
5010-09534-00
5791-12273-02
5791-12273-07
JOKERZ47
...
-
..
_------
- - - - - -----
Description
PC Board
Diode, 1N4004, '.OOA (01)
Relay, 24vdc, 30A
(K1)
Resistor,
on
(Wl, W2)
Header, 2-pin sq post
(Jt)
Header, 7-pin sq post
(J2)
