AUTO RUN - This test rune the hand in a repetitive cycle, launching a ball into the hand popper,
popping the ball into the hand magnet, carrying the ball to the next matrix position, and clearing
the ball from the matrix. During this test, the following data is kept:
CYCLES:
REKICK:
RE-POS:
SW-DRP:
SW-CLR:
SW-NN:
The number of cycles performed.
The number hand popper retries.
The number of hand positioning errors.
The number of times the ball failed to reach the target matrix switch.
The number of times the matrix failed to clear a ball from a switch ( or it was stuck
closed).
This item cycles through each of the matrix switches and displays the number of
errors (SW-DRP or SW-CLR) associated with indicated switch. NN is the Column
and Row numbers of the target switches.
This test will run until either the Escape button is pressed or five consecutive errors occur.
CLEAR AUTO RUN DATA - This test clears all of the results maintained for the Auto Run Test.
1.17 Empty
8alls
Select T.17 from the Test menu and press Enter to begin the Empty Balls Test.
This test kicks out all balls loaded in troughs, lockups, poppers, and kickouts until no balls remain
in those locations.
NOTE:
As
the trough kicks out balls, they will stack up in the shooter groove, which may require
manual cleaning in order to allow further balls to be kicked out.
1-17
