SOLENOID/FLASHER LOCATIONS CONTINUED
Item
Coill
Assy.
No. Flasher No. Number.
21 24-8802 A-17802
22 24-8802 A-17802
23 24-8802 A-20432-5
24 24-8802 A-20432-5
25 24-8802 A-20432-5
26 24-8802 C-13337
27 24-8802 C-13337
24-8802 A-19979
28 24-8802 A-19980
35 A-20099 A-19978
36 A-20099 A-19978
Description
General Illumination Circuits
Item No. Description
Bulb No.
01 Upper Left Playlield
02 Upper Right Playlield
03 Lower Playlield
04 Backbox-Coindoor
05 Backbox Title
G.!. String 1
G.!. String 2
G.!. String 3
G.!. String 4
G.!. String 5
Blue Car
Green Car
Left Jet Flasher
Right Jet Flasher
Center Jet Flasher
Right Side Flasher
Left Side Flasher (2) Flipper Coils
Item No.
Coil No.
Right Ramp Enter Fls. 29 & 30 FL-11629
Diverter Power
31 & 32 FL-11629
Diverter Hold
33 & 34 FL-11629
Color Assy. No.
Description
Blue A-15849-R-2 Lower Right Flipper
Blue A-15849-L-2 Lower Left Flipper
Blue A-14876-R-3 Upper Right Flipper
24-6549 = #44 bulb
24-8704 = #89 bulb
24-8768
=
#555 bulb
24-8802
=
#906 bulb
7
