UPPER PLAYFIELD PARTS
Item
Part Number
Description
Item
Part Number
Description
No.
No.
1 01-9211
"Playfield Hanger Bracket
42 02-4250-36
Spacer 6-32 x 2
1/4"
2 01-13593
Bottom Arch Ball Guide
44 A-17794
Kicker Switch Sub-Assembly
3 A-15849-L-2
Flipper Assembly Complete
45 A-20406
Switch & Bracket Assembly
20-10110-5
Flipper & Shaft Assy., White
A-20451
Coil & Bracket Assembly
4 03-9216-13
Flipper Return Guide, Clear
A-20450
Kicker Assembly, Left
5 A-17813
Rollover Switch Assembly
10-128
Spring
6 A-17811
Sling Shot Kicker Assembly
46 04-10044
Ball Guide Assembly
B-9362-L-2
Coil & Bracket Assembly
47 01-13840
Ball Guide
10-128
Spring
48 12-7293.1
Wire Ramp Support Bracket
7 A-17801
Kicker Count Switch
49 A-14876-R-3
Flipper Assembly Complete
8 02-5107
Adjusting Post
20-10110-5
Flipper & Shaft Assy., White
9 A-19980
Pit Ramp Assembly
50 02-4765-6
Mounting Post 3.13"
10 A-18019-20
Stationary Target, Orange
51 12-7273.2
Turbo Exhaust Ramp
11 A-19978
'Pit Ramp Diverter Assembly
52 04-10058
Ball Guide
A-20413
Diverter Blade & Car Assembly
53 A-20410
Shooter Ramp Assembly
12 A-18159
'10 Opto P.C.B. Assembly
54 A-17811
Sling Shot Kicker Assembly
13 01-13842
Ball Guide
B-9362-R-3
Coil & Bracket Assembly
14 A-18530-1
Stationary Target, Blue
10-128
Spring
15 A-18017-6
Stationary Target, Yellow
55 A-15802-P
Level & Holder Assembly
16 A-19979
Serpentine Ramp Assembly
56 A-15849-R-2
Flipper Assembly Complete
17 01-13843
Ball Guide
20-10110-5
Flipper & Shaft Assy., White
18 A-20407
Turbo Feed Wire Ramp Assy.
57 01-10621
Strike Plate
19 12-6466-10
Ball Guide Wire 2
1/2"
58 A-19963
Ball Trough Assembly, Complete
20 A-20159
Ball Popper Assembly
59 A-18973
Shooter Lane Switch Assembly
21 02-4765-18
Mounting Post 2.41"
60 A-14525
Kicker Bracket Assembly
22 A-18019-6
Stationary Target, Yellow
61 01-13931.1
Left Guard
23 01-14002
Ball Guide
62 01-13932.1
Right Guard
24 01-13912.1
Ball Guide
63 01-13933,1
Left Guard
25 A-20038
Turbo Motor Assembly
64 01-13934.1
Right Guard
A-20065
'Turbo Housing Assembly
65 01-14088
Kicker Ball Guide, Left
03-9343
Turbo Impeller
66 01-10489
Kicker Ball Guide, Right
26 A-19820-1
Illuminated Target Assembly
67 A-20524
One-way Gate Assembly
A-20401
Illuminated Target P.C.B. & Brkt.
27 02-4765-17
Mounting Post 2.25"
NOT SHOWN:
28 04-10203
Ball Guide Assembly
01-12569
Gusset Brackets
29 12-6466-6A Ball Guide Wire 1
5/8"
03-9418-1A
"Full
Playfield Mylar
30 A-20180
Ball Stop Assembly
03-9418-2
Drop Area Mylar (2)
31 A-20235
Ball Popper Assembly
03-9418-3
Upper Left Area Mylar
32 12-7282
Rear Wire Ramp
03-9418-4
Jet Bumper Area Mylar
33 A-20433
One-way Gate Assembly
03-9418-5
Upper Mylar
34 03-8318-9
Double Sided Light Hood, Red
A-15542
Motor EMI P.C.B.
35 A-20170
Back Panel Assembly
A-17812-2
Cable Mounting Bracket
1/2"
36 A-17985-R
Eject Switch Assembly
A-17812-4 .
Cable Mounting Bracket 1"
B-9361-R-1
Ball Eject Assembly, Left
A-20189
Motor EMI
wlDelay
Brake P.C.B.
B-9362-R-3
Coil & Bracket Assembly
A-20501
Playfield Plastic Assy.
10-128
Spring
36-50026
Screened Playfield
37 04-10201
Metal Shooter Ramp
38 A-20169
Race T rack Assembly
MISCELLANEOUS:
39 02-4250-48
Spacer 6-32 x 3"
01-11791
Service Switch Actuator
40 12-6466-5
Ball Guide Wire 1
1/4"
23-6767
Bulb Extractor
41 A-9415-2
Jet Bumper Coil Assembly
A-12030-3
Jet Bumper Switch Assembly
'Located under playfield.
A-20432-5
Jet Bumper Wafer Assy., Orange
"The Indianapolis 500 hardcoat playfield does not
03-9266-12
Jet Bumper Cap, Orange
require a full mylar. However, mylars can be purchased
03-9267-9
Jet Bumper Dome, Red
through your local Bally Distributor.
23-6710-1
Clear Tubing #10,1"
