HIGH SPEED
GAME STATUS DISPLAYS (Continued)
The operator can press the ADVANCE button once to view each Adjustment Information display item. To pro-
ceed more rapidly through this information, the operator only has to press and hold the ADVANCE button. If a
desired item is passed, the operator can use the MANUAL-DOWN switch position with the ADVANCE button to
back up to the desired item.
The
HIGH SPEED Game Adjustment Table
lists the 70 items of the Adjustment Information portion of the
HIGH SPEED
Game Status Displays. Presentation of the displays is similar to that for the Audit Information
(that is, the SPEEDER 1 and SPEEDER 2 displays combine as a descriptive phrase; the light type below the
column headings names the respective backbox displays where the information appears, etc.). The Credits
display shows
Ad
for all 70 adjustment items, so its entry is omitted from the tabular listing.
HIGH SPEED
Game Adjustment Table
•
Adjustment
Descriptive Phrases
Factory
Item
Setting
(MATCH)
(SPEEDER 1 and 2 Displays)
(SPEEDER 4)
01
AUTO REPLAY (%) (or FIXED REPLAY SCORES) 1
10 (%)
02
REPLAY START (or REPLAY LEVEL 1)
1
1,400,000
03
REPLAY LEVELS (or REPLAY LEVEL 2)
1
01
04
(REPLAY LEVEL 3) 1
OFF
05
(REPLAY LEVEL 4) 1
OFF
06
REPLAY AWARD
Credit
07
SPECIAL AWARD
Credit
08
MATCH FEATURE
On
09
BALLS / GAME
03
10
nLTWARNING
03
11
MAXIMUM EX. BALL
04
12
MAXIMUM CREDITS
30
13
HIGHEST SCORES
On
14
BACKUP HI. SCR1
4,000,000
15
BACKUP HI. SCR 2
3,500,000
16
BACKUP HI. SCR 3
3,000,000
17
BACKUP HI. SCR 4
2,500,000
18
HI.SCR1CREDITS
03
19
HI. SCR2 CREDITS
01
20
HI. SCR3 CREDITS
01
21
HI. SCR4 CREDITS
01
22
H. S. RESET EVERY (6,000 PLAYS) 2
23
FREE PLAY
NO
24
U.S.A. 1 COINAGE (1 COIN 1 PLAY) 2,3
25
LEFT UNITS
01
26
CENTER UNITS
04
27
RIGHT UNITS
01
28
UNITSI CREDIT
01
29
UNITS/ BONUS
00
30
MINIMUM UNITS
00
31
FREEWAY START (3-BALL 50,000) 2
32
FREEWAY MEMORY
Regular
33
EJ. HOLE SPOTS (3-BALL YES) 2
34
RAMP SPOTS
YES
35
LIGHT SPECIAL (3-BALL Regular)
2
36
SPECIAL MEMORY
NO
37
POLICE LIGHT
ON
38
KICKBAK MEMORY
EASY
39
LIGHT FREEWAY
Regular
•
