GILLIGAN'S ISLAND 1-31
General IDumination
- -IIi'- ~ ~ ,.__
the test name is shown under the Test Menu, press the Enter button . This test allows you to check
-I1l- -'c ""; of the General Illumination circuits.
There are two modes of operation, Stop and Run. 'Ib obtain
color, driver number, connector, and fuse information,
press the Start button when the desired
.••••'".",••.' Illumination circuit appears in the displays .
...•._ _. _~.-r-
Press the Up or Down buttons to cycle through the General Illumination Test manually.
All
.•. _,
illumination is tested first, followed by an individual circuit test. The circuit name and
.
shows in the displays while the corresponding lamps lights. If any other results
..Occurthe system has detected an error.
Press the Enter button any time during Stop test mode and the General Illumination Test
cycles through automatically.
For each circuit shown in the displays the corresponding
bulbs should light. If any other results occurs the system has detected a problem.
,""~_~"'A~U'"
press the Enter button to return to Stop test mode, or the Escape button to return to the Test Menu.
cc ~ , - · :V,Ll"''''
in the Test Menu press the Up button to advance to the next test, (or the Down button to return to a
previous test). Press the Enter button to activate that test.
Sound and Music Test
Once the test name is shown under the Test Menu, press the Enter button. The Sound and Music Test
. allows you to check the audio circuits. This test has three modes for testing the sound and music
'. circuits, Running, Repeat and Stop.
This test steps through a sequence of sounds and music. Pressing the Up or Down
button during this portion of the Sound and Music test allows you to advance to a
particular sound or tune without having to wait for the program to play all the
sounds available in the test. For each name and number that appears in the
displays a sound or tune should be heard. Any other results indicates the system
has detected a problem.
Press the Enter button at any time during the Running test mode to cause the
program to stop and repeat a particular sound or tune. The same sound should
repeat continuously until the Up or Down button is pressed. Any other results
indicates the system has detected a problem.
Press the Enter button at any time during the Repeat test mode to stop this test
altogether.
Nothing should be heard. Any other results indicates the system has
detected a problem.
Use the Enter button to return to the Running test mode, or the Escape button to return to the Test Menu.
Once in the Test Menu press the Up button to display the next test, (or the Down button to return to a
n.,..,,";nl""
test). Press the Enter button to activate that test.
