Either press the Enter button to return to the Repeat test mode or, press the Escape button to return to the
Test Menu. Once in the Test Menu, press the Up button to display the next test, (or the Down button to
return to a previous test). Press the Enter button to activate that test.
Solenoid Table
Wire Connections Driver
Solenoid Part Number
Sol. Solenoid FI_hlamp Type
No. Function Type Color Tmsb
01 Left Lock High Power Vio-Bm J130-1 082 AE-23-800
02 Island Lock High Power Vio-Red J130-2 080 A-14701
03 Outhole High Power Vio-Om J130-4 078 AE·26-1200
04 Ball Popper High Power Vio-Yel J130-5 076 AE-26-1200
05 Right Sling High Power Vio-Gm J130-6 064 AE-26-1500
06 Left Sling High Power Vio-Blu J130-7 066 AE-26-1500
07 Knocker High Power Vio-Blk J130-8 068 AE-23-800
08 Kickback High Power Vio-Gry J130-9 070 AE-23-800
09 Island Motor Low Power Bm-Blk J127-1 058 14-7964-1
10 Trough Low Power Bm-Red J127-3 056 AE-26-1200
11 Hold Lock Low Power Bm-Om J127-4 054 A-14701
12 Island Light Low Power Bm-Yel J127-5 052 24-8802 #906
13 Left Jet Low Power Bm-Gm J127-6 050 AE-26-1200
14 Right Jet Low Power Bm-Blu J127-7 048 AE-26-1200
15 Bottom Jet Low Power Bm-Vio J127-8 046 AE-26-1200
16 Top Eject Low Power Bm-Gry J127-9 044 AE-28-1500
17 Head 1 Flasher Flasher Blk-Bm J125-1 042 #906 Plfd, #906 Ins
18 Island Flasher Flasher Blk-Red J126-2 J125-2 040 #89 Plfd, #906 Ins
19 Left Bank Flasher Flasher Blk-Om J126-3 J125-3 038 #89 Plfd, #906 Ins
20 Left Flipper Flasher Flasher Blk-Yel J126-4 036 #89 Plfd, #906 Ins
21 Right Flipper Flasher Flasher Blu-Gm J126-6 J125-6 028 #89 Plfd, #906 Ins
22 Head 2 Flasher Flasher Blu-Blk J126-7 J125-7 030 #906 Plfd, #906 Ins
23 Ramp Up Coil Low Power Blu-Vio J126-8. J125-8 034 AE-26-1200
24 Ramp Down Coil Low Power Blu-Gry J126-9 J125-9 032 SM1-26-600
25 Right Bank Flasher Flasher Blu-Bm J122-1 026 #89 Plfd, #906 Ins
26 Treasure Flasher Flasher Blu-Red J122-2 024 #906 Plfd, #906 Ins
27 Titte Flasher Flasher Blu-Om J122-3 022 #906 Ins (2)
28 Professor Flasher Flasher Blu-Yel J122-4 020 #906 Ins
General Illumination Circuits
01 Left Insert String 1 G.I. Wht-Bm J121-7 018 #555
02 Playfield Bottom String 2 G.I. Wht-Org J120-8 010 #555
03 Playfield Middle String 3 G.I. Wht-Yel J120-9 014 #555
04 Right Insert String 4 G.I. Wht-Gm J121-11 016 #555
05 Playfield Top String 5 G.I. Wht-Vio J120-11 012 #555
Lower Right Flipper Blu-Yel J109-7 FL-11630
Lower Left Flipper Gry-Yel J109-5 FL-11630
GILLIGAN'S ISLAND 1-30
(
