Display Circuits
Wire Color
Function
Interboard Wiring
Ribbon Cable
J602 To/from CPU Board
Data
J601 To/from CPU
&
Sound Board
Ribbon Cable
Ribbon Cable
Data
Data
J603 To/from Dot Matrix DisplaY/Driver Board
Connector to Dot Matrix DisplaylDriver
Orange
J604-2
-125V
J604-1
Blue
-1l3V
Black
Ground
J604-4
Gray
J604-6
Black
Ground
J604-5
+5V
GraylYellow
Brown
+12V
+62V
J604-7
J604-S
Connector from Transformer CAC)
White
J605-2
White
SOVAC
J605-1
SOVAC
Violet
Violet
lOOVAC
lOOVAC
J605-3
J605-5
Connector from Power Driyer Board
Black
J606-3
Ground
J606-1
Gray
J606-4
Black
Ground
+5V
Gray
+5V
J606-5
GraylYellow
+12V
J606-6
GraylYe]]ow
Sound Circuits
Wire Color
+12V
Function
J606-7
Ribbon Cable
J506 To/from CPU Board
&
Dot Matrix Controller
Data
Connector From Transformer Secondary
GraY/Green
J501-2
+12VDC J501-1
Gray/Green
+12VDC
Gray
+5VDC
J501-4
J501-6
Gray
+5VDC
J501-5
J501-7
GraylWbite
-12VDC
GraylWhite
-12VDC
Power from CPUlPower Driver Board
Gray
J502-3
+5VDC
J502-1
Gray
+5VDC
Black
Ground
J502-4
Black
Ground
J502-5
Cabinet Speaker Connection
BlacklYellow
. J504-2
Speaker
Backbox Speaker Connection
BlacklYellow
J505-3
Speaker
GILLIGAN'S ISLAND 3-10
