Interboard Wiring
General Illumination Circuits
Connectors from Power Driver Board
Wire Color
Function
To Playfield
To Cabinet
To Insert
Transistor
Green
Feed 1
J121-5
Q12
Violet
Feed 2
J120-6
Jl19-3
QI0
Brown
Feed 3
J121-1
Q18
Yellow
Feed 4
J120-3
Q14
Oran~e
Feed 5
J120-2
J121-2
Q16
White/Green
Return 1
J121-10
F7
WhiteNiolet
Return 2
J120-11
J1l9-1
F6
Wbite!Brown
Return 3
J121-7
FlO
WhitelYellow Return 4
J120-9
FS
White/Oran~e
Return 5
J120-8
J121-S
F9
Power Circuits
Connectors from Power Driver Board
Wire Color
Function
To Playfield
To Cabinet
To Dot Matrix Controller
Gray
Digital +5V
J1l7-4
GraylGreen
Switch +12V
GraylYellow Analog +12V
JllS-2
J116-2
J1l7-2
Black
Ground
JllS-3
Jl16-3
J117-3
Power Circuits
Wire Color
Function
Connectors from Power Driver Board
To Playfield
To Insert
YioletlYellow High Power 50V JI07-3
Violet/Orange
Low Power 50V JI07-2
Violet/Green
Other 50Y
.n
07-1
Red
Flasher 20V
Not Used
RedlWhite
Flasher 20V
JI07-6
WbitelBlue
50VAC
JI04-1
WhitelBlue
50VAC
JI04-2
Black
Ground
JI03-1 2
Logic Circuits
Wire Color
Function
Ribbon Cable
Data
.1201 To
Ifrom
Dot Matrix ControUer
Ribbon Cable
Data
J202 To
Ifrom
Sound Board & Dot Matrix Controller
Ribbon Cable
Data
J204 Not Used
Connectors from Power Driver Board
Black
Ground
J210-1
Black
Ground
J210-3
Gray
+5VDC
J210-4
Gray
+5VDC
J210-5
GraY/Green
+12VDC J210-6
Gray/Green
+12VDC J210-7
Ribbon Cable
Data
J211
