T.6 General Illumlnatlon
Once the test name is shown under the Test Menu , press the Enter button. This test allowsyou to
check all of the General Illuminat ion circuits. There are two modes of operation, Stop and Run.
To obtain wire color, driver number, connector, and fuse information, press the Start button when
the desired General Illunination circuit appears in the displays .
Stop- Press the Up or Down buttons to cycle through the General Illumination Test manually . All
illumination is tested first, followed by an individual circuit test. The circuit name and
number shows in the displays while the corresponding lamps lights. If any other results
occur the system has detected an error.
Run - Press the Enter button any time during manual testing and the General Illumination Test
cycles through automatically. For each circuit shown in the displays the corresponding
bulb should light . If any other results occurs the system has detected a problem .
Either press the Enter button to return to Stop Test, or the Escape button to return to the Test Menu .
Once in the Test Menu press the Up button to advance to the next test, the Sound and Music Test.
T.7 Sound and MusicTest
Once the test name is shown under the Test Menu, press the Enter button. The Sound and Music
•
Test allows you to check the audio circuits. This test has three mode s for testing the sound and
music circuits, Running , Repeat and Stop.
Running -
Press the Enter button when Sound and Music Test is displayed. This test steps
through a sequence of sounds and music . Pressing the Up or Down button during
this portion of the Sound and Music test allows you to advance to a parti cular sound
or tune without having to wait for the program to play all the sounds available in the
test. For each name and number that appears in the displays a sound or tune
should be heard . Any other results indicates the system has detected a problem.
Repeat-
Pressing the Enter button at any time during the Running portion of the Sound and
Music Test causes the program to stop and repeat a particular sound or tune. The
same sound should repeat continuously until the Up or Down button is pressed. Any
other results indicates the system has detected a problem.
Stop-
Press the Enter button at any time during the Repeat test to stop this test altogether .
Nothing should be heard . Any other results indicates the system has detected a
problem .
Use the Enter button to retum to the Run test, or the Escape button to return to the Test Menu. Once
in the Test Menu press the Up button to display the next test , the Single LampTest.
"
•
FUNHOUSE 1-30
