STANDARD GAME PRICING
This feature accounts for differences in coin door
mechanisms and how credits are awarded. Function 19can
be set to select one of seven standard game pricing schemes
with fixed values for Functions 20 through 24. (Function 19
can also be set to allow custom pricing schemes where
Functions 20 through 24 are set with appropriate values as
described in the CUSTOM GAME PRICING paragraphs).
To select one of the standard pricing schemes, proceed as
follows:
1. If not already in test 04, enter test 04 in one of the
following ways:
a. From the game over mode, set the AUTO-
UP /MANUAL-DOWN switch to AUTO-UP and
depress the ADVANCE pushbutton.
b. From diagnostics, set the AUTO-UP/MANUAL-
DOWN switch to AUTO-UP and depress the
ADVANCE pushbutton to advance the diagnostics
to test 04.
2. Set the AUTO-UP/MANUAL-DOWN switch to the
desired position and operate the ADVANCE push-
button until Function 19is indicated on the ball in play
display.
3. Refer to Table 2 and determine the value of Function 19
required for the desired pricing scheme. (Standard
pricing is set in bold type).
4. To raise the value of Function 19 set the AUTO-
UP/MANUAL-DOWN switch to AUTO-UP.
To lower, set it to MANUAL-DOWN.
S. Operate the Credit button until the value determined in
step 3 is shown in the Player 1 display.
6. If no further came adjustments are required, turn the
game OFF and back ON to return to the game over
mode.
CUSTOM GAME PRICING
With Function 19 set to zero, the five Functions 20 through
24 may be set manually for custom game pricing
requirements. Functions 20, 21, and 22 relate to the type of
coin door mechanism and Functions 23 and 24 relate to how
credits are awarded. A large number of custom game pricing
schemes are provided in Table 2 and are set in light type. If
the required pricing scheme is not provided in Table 2, refer
to the explanation that follows the procedure to determine
the values for Functions 20 through 24. Proceed as follows:
1. If not already in test 04, enter test 04 in one of the
following ways:
a. From the game over mode, set the AUTO-
UP/MANUAL-DOWN switch to AUTO-UP and
depress the ADVANCE pushbutton.
b. From diagnostics, set the AUTO-UP/MANUAL-
DOWN switch to AUTO-UP and depress the
ADVANCE pushbutton to advance the diagnostics
to test 04.
2. Set the AUTO-UP/MANUAL-DOWN switch to the
desired position and operate the ADVANCE push-
button until Function 19 is indicated on the number of
credits display.
Table 2. Standard and Custom Pricing Settings
COIN DOOR FUNCTION
MECHANISM CREDITS 19* ZO ZI Z2 Z3 24
Quarter, 1/15,,3/50, 01 01 01 01 01 02
Twin-Quarter, 1/1Sc 01 01 01 01 01 00
or 3-Quarter 2/25¢, 5/50¢ 00 02 02 02 01 04
2/25¢ 00 02 02 02 01 00
1/5001 00 01 01 01 02 00
1/50¢,3/$1 00 01 01 01 02 04
1/75¢ 00 01 01 01 03 00
Nlckel-Dime- I/Z'¢,3/'U¢ UU UI Oz U' Uj IU
Quarter 1f25¢ 00 01 02 05 05 00
2/25¢ 00 01 02 05 05 05
1/ 15¢, 2/25¢ 00 02 04 10 05 00
1/ IO¢, 3/25¢ 00 03 06 15 05 00
IDM, jUM, ZUM J.fIUM, ~fJ.UM, 14f~UM Uj lj O~ Z6 05 65
20-Cent, 50-Cent tIZU¢, 3/jU¢ 00 u6 00 15 05 00
I Franc, ) •. ranc I/IF,6/SF 04 01 00 OS 01 OS
I/1F,7/SF OS 06 00 30 OS 30
L) Lent, I ouucer I/ZSt u6 ul uu 04 UI OU
If25¢,5/IG 00 01 00 04 01 04
50 Yen, _I00Yen I 'SOY. Z/IOOY U7 Ul UU OZ 01 _III)_
1 •.ranc or 1/11', 3/Z1' OJ 01 UI 01 OJ OZ
I Franc, I •. ranc 1 'IF 02 01 01 01 01 00
5 •.ranc, 10 Franc 1/5},', 2/ loti 07 01 00 02 01 00
IflOF 00 01 00 02 02 00
2 Franc, 2 Franc lIlt 02 01 01 01 01 00
10 Franc, 20 Franc 1/101', ZIZOI' 07 01 00 _cg_ 01 00
I Sucre, I Sucre 1!3S,2/5S 00 02 00 02 05 00
·Function 19 set to values 01-07 automatically selects correspondi ng values of Functions 20-24. With Function 19 set
to 00, Functions 20-24 must be set manually.
