Building Lamp Board
pIn
C-12427
Part No.
5768-12355-00
24-8767
24-8768
5070-09054-00
5791-10869-12
Description
Building Lamp P.C.B.
Twist Lamp Socket
Bulb, #555 (6.3v, .25A)
Diode, 1N4004, 1.0A
Header, 12-pin sq post
Lamp Board (n8_Ln)
pIn
C-12491
Part No.
5768-12370-00
24-8767
24-8768
5070-09054-00
5791-10871-10
Description
PC Board
Twist Lamp Socket
Bulb, #555 (6.3v, .25A)
Diode, 1N4004, 1.0A
Header, 1O-pin sq post
Lamp Board (n6_Rn)
pIn
C-12496
Part No.
5768-12375-00
24-8767
24-8768
5070-09054-00
5791-10871-07
Description
PC Board
Twist Lamp Socket
Bulb, #555 (6.3v, .25A)
Diode, 1N4004, 1.0A
Header, 7-pin sq post
o
o
Kl
Relay Board
(Sol. 10 & 15 Gen. ilium)
pIn
C-11902-1
Part No.
5768-12221-00
5070-09054-00
5580-12145-00
5791-12273-02
5791-12273-07
Description
PC Board
Diode, 1N4004, 1.0A
Relay, 24vdc, 30A
Header, 2-pin sq post (J1)
Header, 7 pin sq post (J2)
Lamp Board (n6_e n )
pIn
C-12490
Part No.
5768-12369-00
24-8768
24-8767
5070-09054-00
5791-10871-08
Description
Bonus PC Board
Bulb, #555 (6.3v, .25A)
Twist Lamp Socket
Diode, 1N4004, 1.0A
Header, 8-pin sq post
Lamp Board (n5_Rn)
pIn
C-12492
Part No.
5768-12371-00
24-8767
24-8768
5070-09054-00
5791-10871-07
Description
PC Board
Twist Lamp Socket
Bulb, #555 (6.3v, .25A)
Diode, 1N4004, 1.0A
Header, 7-pin sq post
Lamp Board ("7-Dn)
pIn 0-12501
Part No.
57,68-12377-00
24-8767
24-8768
5070-09054-00
5791-10871-09
Description
PC Board
Twist Lamp Socket
Bulb, #555 (6.3v, .25A)
Diode, 1N4004, 1.0A
Header, 9-pin sq post
0
<m>-
0
Wl-c:::J-
W2c..:J-
5580-09555-
01
::D
r-
<
1,.----"""'\ ,. "
5580-12145-00
i
1
ill
II II
" "
- N
UU
o
Relay Board
(Sol. 11 Gen. ilium)
pIn
C-11998-1
Part No.
5768-12243·00
5070-09054-00
5580-09555-01
5010-09534-00
5791-12273-02
5791-12273-07
EARTHSHAKER 47
Description
PC Board
Diode, 1N4004, 1.00A (01)
Relay, 24vdc, 30A (K1)
Resistor,
on
(W1, W2)
Header, 2-pin sq post
(J1)
Header, 7-pin sq post
(J2)
