Adjustment Items 01 through 70
The coin door must be open to access the Game Adjustment/Diagnostic switches.
All readings and setting changes require operation of these coin door SWitches.
Some setting changes utilize the Start button; Adjustment #49 also uses the flipper
buttons. Additional text describing the game adjustment items follows this
procedure; the value of the Factory Setting for each Game Adjustment item is in the
preceding DR.
DUDE
Game Adjustment Table.
1. Use AUTO-UPand press ADVANCE.The Id 00 display initially appears.
Press ADVANCEuntil the Player 3 display indicates Ad 01. If the
factory setting has not changed, the Player 1 and 2 Score displays
indicate AUTOREPLAY,and the Player 3 display shows 10%, indicating a
lOOk
replay percentage. (The game program adjusts itself automatically,
as discussed in the followingtext concerning the 'details' about
Adjustment Item 01.)
2. To reach a higher item number (in the Player 3 display), use AUTO-UP
and press ADVANCE.To retum to a previous item number, use
MANUAL-DOWNand press ADVANCE.
3. With the desired Game Adjustment Item number showing in the Player 4
display, increase the setting value (or select another option) shown in the
Player 3 display by using AlITO-UPand pressing the Start button.
Repeat this step for each item, until all changes to the factory settings for
the Game Adjustment Items have been made. The preceding Game
Adjustment Table consolidates the Factory Settings into one grouping.
(The same procedure can be used for Audit Items. To zero Au 01 - 04
(concerning the coin chutes and the total coins], the operator can
proceed to item 70, Clear Coins, and press the Start button to obtain
the YES option. The operator then presses the ADVANCEbutton and
notes the "DONE" display, which verifies that the entry values for items
01 through 04 of the Audit Items are now reset to zero.)
For example. the operator may desire to change the degree of game play
difficulty from the Factory Setting (equivalent to the Install Medium (Ad
64) difficulty, along with a number of other automatically installed
settings, as shown in the right column of the Game Adjustment Table) to
another difficulty more suitable for the players at a particular game site.
Four other 'automatic' play difficulty settings (Ad62 - Ad 66) are
available, each ofwhich, if selected. installs all the adjustments listed for
that difficulty in the Game Adjustment Setting Comparison Table, which
precedes the 'details' text.
4. To proceed rapidly through the entire adjustments series. press and
hold ADVANCE.until Ad 70 shows in the Player 4 display. From item
70. you can: (A)retum to the Game-Over Mode; or (B)clear the coinage
audits (Au01 through 04). Perform either of the following, as desired:
1-14 Game Adjustments
