GAME ADJUSTMENT PROCEDURE
(Continued)
SIPIEC~AlIPIRlIESIETAIDJUSTMIE~TS CAUT~O~
Adjustments 53 through 66 are Special Preset Adjustments to enable the operator to perform the
setting of multiple adjustments at once. They permit the operator to: (1) modify a game
for
a
specific area (special German coinage settings, for example, Ad 53 through 58); (2) change a
group of adjustments to conform with laws of certain localities (Ad 59 through 61); and (3) to
change the degree of difficulty of game play (Ad 62 through 66). A list of the preceding individual
Adjustments affected accompanies each of these Special Preset Adjustments. Whenever the
operator chooses to use
any
Special Preset Adjustment, the operator can later access
any
or all of
the individual Adjustments affected by that Special Adjustment for subsequent changes.
A similar technique is recommended in the event of error or uncertainty concerning
any
Special
Preset Adjustment, after the operator selects it: The operator can restore the factory setting of
each individual Adjustment, then select the desired Special Preset Adjustment, and then return to
any
of the preceding individual adjustments to determine whether use of the Special Adjustment
has had the desired effect.
The Backbox displays for each Special Preset Adjustment indicate whether the operator has
selected it, by identifying the Adjustment in the Player 1 and 2 displays by name and the selection
choice of NO, meaning Not Selected (this is the Factory Setting), or YES, meaning Selected, in the
Player 4 display. Operator installation of the 'selected' Preset Adjustment occurs by using the
Credit button to choose YES and then pressing the ADVANCE switch. The displays then show the
name of the Adjustment again, with DONE to show that the installation is now in effect.
Note that, when an operator installs
any
of the Special Preset Adjustments, Adjustment Items
using the automatic adjust feature of the game program reset to the auto adjust value listed for that
Adjustment Item.
NOTE
Games in which the
cpu
jumper W7 is cut ("German games") automatically have certain
Adjustment Items preset:
Ad Name
01 Auto Replay
02 Replay Start
03 Replay Level 2
12 Maximum Credits
14 Backup Hi Scr 1
15 Backup Hi Scr 2
16 Backup Hi Scr 3
17 Backup Hi Scr 4
New Setting
15
(%)
2,500,000
03
30
5,500,000
5,000,000
4,500,000
4,000,000
Ad Name
18 Hi Scr 1 Credits
19 Hi Scr 2 Credits
20 Hi Scr 3 Credits
21 Hi Scr 4 Credits
22
24
47
51
Hi Scr Reset
German 2 Coinage
Consol. Time
Deutsch Text
New Setting
03
00
00
00
750 games
7 Piays/5DM
60 sec
Deutsch
53 Install
German 1
The operator can modify the game pricing selection of Standard Setting 09 in the Pricing
Table to permit Credit Award play with 10 games for 5 OM. Individual Adjustments are affected,
as follows:
M~
New Setting
Ad.
Name
~ew Setting
06 Replay Award
Credit
17 Backup Hi Scr 4 4,000,000
07 Special Award
Credit
18 Hi Scr 1 Credits
03
08 Match Feature
10%
19 Hi Scr 2 Credits
00
14 Backup Hi Scr 1 5,500,000
20 Hi Scr 3 Credits
00
15 Backup Hi Scr 2 5,000,000
21 Hi Scr 4 Credits
00
16 Backup Hi Scr 3 4,500,000
24 German 1 Coinage 10 Piays/50M
54 Install
German 2
The operator can modify the game pricing selection of Standard Setting 09 in the Pricing
Table to permit Ticket/Token operation with 10 games for 5 OM. Individual Adjustments are af-
fected, as follows:
CYCLONE 19
