10. The TRU-PITCH™ level is located on the right shooter rail. This allows the playtleld pitch angle to
be properly adjusted WITHOUT REMOVING THE GLASS. The first line (closest to the front of the
game) on the level is approximately 6 degrees. Every line thereafter is approximately another
1/2
degree of pitch. The recommended pitch is
6-1/2
degrees. The NOSE of the bubble should be
between the first and second line on the level (see diagram below).
TRU- PITCH™level 6-1/2 degrees.
I
I
I
I
I
IMPORTANT!
Playfield pitch angle can affect the operation of the plumb bob tilt. The plumb bob weight is among
the parts in the cash box; the operator should install the weight and adjust this tilt mechanism for
proper operation, after completion of the desired playfield pitch angle setting. The unit is factory
installed for
a
6-1/2
degree angle. If an adjustment is necessary, loosen the screw at the bottom of
the unit. Move the pointer, one grove at
a
time to the left or the right, depending on the degree
. desired. Hold the pointer in place and tighten screw
11.· Be sure the
required number
of balls is installed. The
CIRQUS VOLTAIRE
game uses FOUR
balls.
12. Install full playfield Mylar, if desired.
Note: The
CIRQUS VOLTAIRE
playfield is coated with a special hardcoat surface and does not
require a protective Mylar. However, mylars can be purchased through your local Williams
Distributor. Specifypart number 03-9700-1 for full playfield Mylar.
13. Clean and reinstall the playfield cover glass. Heplace and lock the front molding.
14. To attach the line cord, remove the four Phillips-head screws that mount to line cord cover plate to
the rear cabinet. Match the prongs on the plug with the holes in the receptacle, and push the line
cord securely into place. Make sure the cord is aligned with the indentation on the cover plate
(indentation should paint toward bottom of the cabinet). Remount line cord cover plate. If desired,
four tamper resistant screws have been provided, in the unique parts bag, to remount cover plate.
(Part of cabinet shown
for reference only) ~
15. Move the game into the desired location; recheck the level and pitch angle of the playfield.
1-4
