Raise the hinged backbox upright and latch it into position ..
Note: This game doesn't use a speaker panel. Instead the insert panel and speakers are attached
to the backglass.
The speakers, insert panel, and backglass form
a
single unit in the backbox
housing.
Unlock the backbox. Carefully, lift the backglass/insert panel from the bottom. Slide it down and
out of the backbox grooves. Rotate it forward and lay it down on the playfield glass. Unplug the
cables extending from the backbox to the insert panel and speakers.
Carefully, set the
backglass/insert panel aside.
Once the backglasslinsert panel is removed the holes needed to secure the backbox upright are
accessible. To secure the backbox, install the washer-head mounting bolts through the holes in the
bottom of the backbox. Be sure that the bolts extend into the threaded fasteners in the cabinet.
After the washer-head mounting bolts are installed, replace the backglass/insert panel. Take care
when plugging in the connectors. Connectors should plug in easily. Do not force the connectors.
&
CAUTION
FAILURE TO INSTALL
the backbox mounting hardware properly. can cause personal injury.
NEVER TRANSPORT
a pinball game with the hinged backbox erect. Always lower the backbox
forward onto the playfield cabinet on a layer of protective material to prevent marring or damage
and possible personal injury.
Extend each leg leveler
slightly
below the leg bottom, so that all four leg leveler pads are extended
about the same distance. Remove the cabinetfrom its support and place it on the floor.
Unlock and open the coin door. Move the lever glJide toward the left. side of the game, and lift the
front molding off of the· playfieJd cover glass. Slide the lever ,guide to the right, and close the coin
door. Carefully slide the glass downward, until it clears the 'grooves of the left and right side
moldings. Lift the glass up and away from the game, storing it carefully to avoid breakage.
PLAYflELD GLASS
LEVER GUIDE ASSEMBLY
ON/OFF SWITCH
Place a level or an inclinometer on the playfield surface. Adjust the leg levelers for proper playfield
level (side-to-side).
Note:
This measurement must be made ON the p/ayfieJd, not the cabinet or the p/ayfie/d cover
glass.' Tighten the nut on each leg leveler shaft to maintain this setting.
1-3
