(B) '.Plugs securely seated in sockets.
(C) Dress cables away from relays.
Check adjustment of the three (normally open) tilt switches:
(A)
(~)
,(C)
Panel tilt on bottom of playfield panel.
Plumb
bob tilt on
left side of cabinet
near
front
door.
-
.
Ball
tilt
above plumb.
bob til , t.
.
Insert the smaller ball (15/16" ,dia.) into the ball tilt
assembly, and adjust the bracket so the ball will roll
free to contact the switch blade, if front of cabinet is
raised.
Plug
in line cord:
Check adjustment of the (no~lly open) kick off swtich at
rear
of
cabinet. mounting board near cable plugs. Check adjustment of the
(norma';t.~y
.open) anti slam switch, on front door.
If
either
of
those switches is closed, the delay relay is energized momentarily.
General
Game
Operation:
Place ball into playfield
by
outhole.
Coin Game:
If coin should be rejected move on-off master switch at bottom
right
front corner of cabinet to
"on"
position, then coin game. Coin
lock out device rejects all coins when power (master swtich) is
off. ~lso check the del_ay relay. If this relay is energized, the
game will, not_accept coins.
LA. If coin is inserted in 1st (nickel) coin chute and game is
conditioned for 1 play - 5¢,
it
will energize the coin rela1.
If game is conditioned for 1 play - lO¢, the first coin
in-
serted will advance the 2 coin unit, then second coin
insert-
ed
will
energ.ize
the coin
relay thru the 2 coin
uJlit
s\1iitch.
(See 1st coin chute adjustment plug
positions
on
game adjust-
ments
sheet).
lB. If coin is inserted i~ 2nd (dime)
coin
chute and game is con-
ditioned for 1
play -
lO¢, it will energize
the
coin relay.
If game is conditioned for 2 play - lO¢, it will energize the
2nd coin
chute
relay
and 2·nd
coin
chute
relay
will
advance
the credit unit (2
steps)
thru the credit circuit. (See
2nd
coin chute
adjustment
plug positions on game
adjus.tments
sheet).
le.
If coin is inserted in 3rd (quarter) coin chute and game is
conditioned for 2-3-4-5 or 6 plays - 25¢, it will energize
the 3rd coin chute relay and the 3rd coin chute relay will
advance the credit unit (2-3-4-5-6 steps) thru the credit
circuit. (See 3rd coin chute
adjustment
plug positions on
game adjustment sheet).
-2-
