CONNECTOR & COMPONENT IDENTIFICATION
WILLIAMS ELECTRONICS GAMES uses a special technique to identify connectors. Each plug or
jack receives a prefix number (which identifies the circuit board), a letter, and a number.
J-designations refer to the male part of a connector. P-designations refer to the female part of a
connector. For example, 1J1 designates jack 1 of board 1 (a CPU Board jack); 3P6 designates plug 6
of board 3 ( a Power Supply Board plug). Identifying the specific pin number of a connector involves a
hyphen, which separates the pin number from the plug or jack designation. For example, 1J1-3 refers
to pin 3 of jack 1 on board 1.
Other game components may also have similar prefixes preceding their designator to clarify their
locations or related circuit.
Prefix numbers for the System 11B circuit boards and other major assemblies are listed below. A prefix
number may precede a component designator to identify its associated unit (e.g., connector lJ1).
1 -
CPU
2 - Master Interconnect
3 - Backbox Power Supply
4 - Alphanumeric Display
5 -
Aux Power Driver
6 - Backbox
7 - Cabinet
8 - Playfield
9 - Insert Board
, 0 - Audio
1l1atk ltnigbt 2000
CIRCUIT BOARDS
System 11B Circuit Boards for
JHadt
1ntg~t
2000
are in the backbox. They are accessible by
unlocking the Backbox lock, removing the Backbox glass, unlatching the Insert Board (with lamps),
and swinging it open.
The Master Display Board is mounted on the back of the Speaker/Display Panel, just below the Insert
Board. To access the Master Display Board, carefully lift the Speaker/Display Panel out of its bottom
guide and lay it forward onto the top of the game cabinet.
Lamp circuit boards are mounted on the Playfield and the Insert Board.
CPU BOARD. The System 11B CPU Board (pIn D-11883-563) must be equipped with the
ROMs specified in the
~latk 1n
tgbt
2000
(System 11B) ROM Summary. CPU Board
jumpers W1, W2, W4, W5, W7, W8, W11, W14, W16, WH, and W19 must be connected.
AUDIO BOARD. The Audio Board is
pIn
D-11581-563, including ROMs and microprocessor.
DISPLAY BOARD. The Alphanumeric Display Unit Board is pIn D-12232-1.
POWER SUPPLY BOARD. The Power Supply Board is pIn 0-12246.
AUX POWER DRIVER BOARD. The Aux Power Driver Board is 0-12247-563.
MASTER INTERCONNECT BOARD. The Master Interconnect Board is 0-12313-563.
Figure 1 shows the locations of these circuit boards, as well as other devices especially located to
make
Jllatk
1utgbt
2000
a great game.
