Section 1
@@fJi1J@ @(JJ@!l&111uc§)[fJ
@
If@~a O@(J@flWiJ@aU@@
• lLllatk ltu 19bt 2000 (System 11B) ROM Summary
• Pinball Game Assembly Instructions
• Game Play
• Game Status Displays
• Game Adjustment Procedure
• Game Pricing
• Test/Diagnostic Procedures
1JiHatk ltlltg~t 2000 (System 118) ROM Summary
IC DESCRIPTION TYPE IDENTIFIER BOARD PART NUMBER
Game ROM 1 32K x 8 ROM 27256 U27 CPU A-5343-563-2
Game ROM 2 32K x 8 ROM 27256 U26 CPU A-5343-563-1
Sound ROM 1 32K x 8 ROM 27256 U21 CPU A-5343-563-4
Sound ROM 2 32K x 8 ROM 27256 U22 CPU A-5343-563-3
Music/Speech ROM 1 32K x 8 ROM 27256 U4 Audio A-5343-563-5
Music/Speech ROM 2 32K x 8 ROM 27256 U19 Audio A-5343-563-6
IlJrfJ7l'llClE
To order a replacement ROM from your authorized WILLIAMS ELECTRONICS GAMES
distributor, specify: (1) part number (if available); (2) ROM label color; (3) ROM level
(number) on the label; (4) which game the ROM is used in.
