Parts Information
Ramp Assembly
pin 8-12636
Item Part No.
1 H-12685
2 5647-12073-20
3 01-8240
4 5070-06258-00
5 Not Used
6 B-12637
a) 01-8323
b) 01-9118
7 4002-01005-08
8 4701-00024-00
Description
Ramp Switch Cable
Subminiature Switch
Nut Plate
#
2-56
Diode, 1N4001, 1.0 A.
Ramp Sub-Assembly
Switch Bracket
Ramp
Mach. Screw, #2-56 x 1/2
Lockwasher, #2 Split
Top Ramp Assembly
pIn
C-12674
Item Part No.
1 03-8260
2 01-8433
3 07-6688-19N
4 01-9144
5 07-6688-18N
6 4700-00003-00
7 31-1006-563-34
8 4106-01033-08
Description
Top Ramp
Mounting Bracket
Rivet, 1/8 x 7/32
Top Ramp Flap
Rivet, 1/8 x 3/16
Flatwasher, 1/8 x 9/32 x 21ga.
Playfield Plastic
Sh. Metal Screw, #6 x 1/2
MICROSWITCH
MOUNTING BRACKET
RAMP ASSEMBLY
TOP RAMP ASSEMBLY
Microswitch Mounting
Bracket
pIn
01-8719
