Jet Bumper Assembly
pIn 8-9414-2
Item
Part
No.
Description
1 A-4754
2 03-6009-A5
3 03-6035-6
4 03-7443-5
5 10-7
6 A-11199
Bumper Ring Assy
Bumper Base-Wht
Bumper Wafer-Vel
Bumper Body-Wht
Spring-Jet Bumper
Socket
&
Bulb ASsy
Jet Bumper Coil Assembly
pIn 8-9415-1
Item
Part
No.
Description
1 B-7417
Bracket
&
Stop Assy
2 01-1747
Coil Retaining Bracket
3 01-5492
Armature Link, Steel
4 01-5493
Armature Link, Bakelite
5 02-3406-1
Coil Plunger
6 10-326
Armature Spring
7 AE-23-800
Coil Assembly
8 4006-01017 -04 Mach. Screw, 6-32 x 1/4
9 03-7066
Coil Tubing
Eject Hole Arm Assembly
pIn
8-9361-R-5
Item
Part
No.
Description
1 A-6949-R
2 A-8268
3 A-7471-R
4 A-8050-1
5 10-320
6 12-6227
7 4700-00030-00
8 4700-00103-00
Spring Plate Assy
Mounting Bracket Assy
Eject Cam Assembly
Plunger Assembly, 2-1/8
Eject-Spring (Red)
Hairpin Clip
Flat Washer, 17/64 x 1/2 x 15ga.
Flat Washer, 17/64 x 1/2 x 28ga.
Associated Parts For Eject Hole
B-11203-R-1
B-7572-1
01-8-508-S
4006-01017 -06
4406-01119-00
AE-26-1500
03-7066
Coil & Bracket Assembly
Bracket
&
Stop Assembly
Coil Retaining Bracket
Mach. Screw, 6-32 x
3/8
Nut, 6-32 ESN
Coil Assembly
Coil Tubing
JET BUMPER ASSEMBLY
JET BUMPER COIL ASSEMBLY
EJECT HOLE ARM ASSEMBLY
