GAME ADJUSTMENT PROCEDURE
(Continued)
SPIECiAl PRESET ADJUSTMENTS CAUTION (Continued)
Whenever the operator chooses to use any Special Preset Adjustment, the operator can later
access any or all of the individual Adjustments affected by that Special Adjustment for subsequent
changes.
A similar technique is recommended in the event of error or uncertainty concerning any Special
Preset Adjustment, after the operator selects it: The operator can restore the factory setting of
each individual Adjustment, then select the desired Special Preset Adjustment, and then return to
any of the preceding individual adjustments to determine whether use of the Special Adjustment
has had the desired effect.
The Backbox displays for each Special Preset Adjustment indicate whether the operator has
selected it, by identifying the Adjustment in the Player 1 and 2 displays by name and the selection
choice of NO, meaning Not Selected (this is the Factory Setting), or YES, meaning Selected, in the
Player 4 display. Operator installation of the"selected' Preset Adjustment occurs by using the
Credit button to choose YES and then pressing the ADVANCE switch. The displays then show the
name of the Adjustment again, with DONE to show that the installation is now in effect.
Note that, when an operator installs any of the Special Preset Adjustments, Adjustment Items
using the automatic adjust feature of the game program reset to the auto adjust value listed for that
Adjustment Item.
53-55 Not Used
56 Install One Coin
The operator can select the Standard Setting "U.S.A, 3", as shown in the Pricing Table, and
also select the value of Regular for Adjustment Ad32. The choices are
Yes
(Select USA 3 [1
play/1 -25¢ coin] and Ad32
=
Regular) and
No
(Factory Setting USA 2).
57 Install
3/$1
The operator can select Standard Setting "U.S.A. 2", as shown in the Pricing Table, rather
than one of the other Standard Settings. The choices are
Yes
(Select USA 2 [1 play/2-2S¢
coins or 3 plays/4-2S¢ coins] or
No
[Another Standard Setting must be selected]). This is the
Factory Setting.
58 Install 2 Coins
The operator can select Standard Setting "U.S.A. 1", as shown in the PriCing Table, rather
than another Standard Setting. The choices are
Yes
(Select USA 1 [1 play/2-2S¢ coins or 2
playS/4-2S¢coins] or
No
[Another Standard Setting must be selected)).
59 Install Add-A-Ball
The operator can utilize this option to delete all Free Play awards and replace them with Extra Ball
awards. Individual Adjustments are aHected,as follows:
.Ad.
Name
NflWSfllling
ill!
Name
New Setting
06 Replay Award
Ball
18 Hi Scr 1
creots
00
07 Special Award Ball
19 Hi Scr 2 Credits 00
08 Match Feature OH
20 Hi Scr 3 Credits·
09
21 Hi Scr 4 Credits
' 00
