For FIXED REPLAY, Ad 02 is the first replay level (REPLAY LEVEL 1). Ad 03, 04, and 05 are
the other replay levels.
'.
GAME ADJUSTMENT PROCEDURE
(Continued)
4. To proceed rapidly through the entire adjustments series, press
and hold
ADVANCE, until
Ad 70 shows in the Player 3 display. From item 70, you can: (A) return to the Game-Over
M.Q.d.e.;
or (8) restore factory settings and zero audit (bookkeeping) totals. Perform either of
the following, as desired:
A. To reach Game-Oyer Mode, use AUTO-UP and press ADVANCE once.
BANZAI RUN
now
goes to the Game-Oyer Mode.
8. To restore the Factory Settings for Game Adjustment Items (as listed in the Game
Adjustments Table), zero all audit (bookkeeping) totals,
and
return to Game-Over Mode,
use AUTO-UP or MANUAL-DOWN to display Ad 70 in the Player 3 display. Press the
Credit button to display the YES option in the Player 4 display. Using AUTO-UP, press
ADVANCE once.
BANZAI RUN
now zeroes ALL Audit Item totals and changes ALL Game
Adjustment Items back to those originally selected as Factory Settings. It then shows the
operator a message ("FACTORY SETIING") that this has occurred. (A problem in the
Memory Protection circuit or closing the coin door will cause the message "ADJUST
FAILURE" to appear.) Press ADVANCE once more to return to the Game-Oyer Mode.
Details of Adjustment
Items 01 through 70
01 Auto Replay (or Fixed Replay)
Of the two options, AUTO REPLAY is the percentage of replays automatically awarded per
game. The game program aids a pinball's initial installation by causing a comparison of the value
of the Replay Level to the value of all players' scores every 50 games for the first 1,000 games.
At each comparison, the program increases (or decreases) the Replay Level by an amount
necessary to achieve the replay percentage specified either via the factory setting (or later
operator selection). (After the first 1,000 games, the comparison occurs after every 500 games.
The adjustment value is 100K, for this (and each subsequent) comparison.) Use the Credit
button to change the percentage within the range of 5to 25
(%),
with the value increasing using
AUTO-UP (or decreasing using MANUAL-DOWN). The next Credit button change below 5%,
selects the FIXED REPLAY option.
For AUTO REPLAY, Ad 02 provides the Starting Replay Level (Player 1 and 2 displays show
REPLAY START). Ad 03 provides the number of replay levels (01, 02, 03, or 04).
BANZAI
RUN
then proceeds to Ad 06 automatically.
02 Starting Replay Level (or Replay Level 1)
For AUTO REPLAY (refer to Ad 01), the initial Factory Setting is listed in the Game Adjustment
Table, but this will change when the game compares the players' scores with this adjustment's
value during its auto adjustment activity. The range of settings is
1,000,000
t03,000,000
by
increments of 100,000 with AUTO-UP or decrements of 100,000 with MANUAL- DOWN).
For FIXED REPLAY, the operator can enter the value to be used for the first fixed replay score
level via the Credit button. The range of settings is:
OFF; 100,000
through
9,900,000
(by
increments of 100,000 with AUTO-UP, or decrements of 100,000 with MANUAL-DOWN).
