A-20608
Saucer Assembly
Item Part Number
Description
Item Part Number
Description
1 A-20713
Saucer Assembly
11 03-7067-3
Coil Tubing
2 04-10315
Saucer Support Weldment
12 A-20718
Xenon Flash Tube Assembly
3 03-9478
Strobe Light Cover
13 H-19523
Coil Cable
4 03-9470
Saucer Coil Cover
14 01-8-508-T
Coil Retainer Bracket
5 04-10361
Saucer Armature
15 4008-01003-04 Mach. Screw, 8-32 x 1/4"
6 23-6420
Rubber Grommet
16 01-14220
Strobe Light Insulator
7 03-9454
Tie Wrap
17 5797-14773-00 Strobe Cable
8 4408-01119-00 Nut 8-32 ESNA
18 AE-26-1500
Coil Assembly
9 10-135
Armature Spring
19 4008-01017-05 Mach. Screw, 8-32
10 4700-00009-00 FW, 11/64 x 7/16 x 22ga.
2-21
