Ramp Diverter Assembly
2
Item Part Number
1 01-11957
2 A-12390
3 01-7695-0
4 20-8790
5 A-20099
6 4006-01017-04
7 4010-01066-06
8 4701-00004-00
9 03-7066-5
10 A-16636
11 10-303
12 A-14185
13 4010-01169-04
Description
Ramp Diverter Mounting Bracket
Flipper Stop Bracket Assembly
Solenoid Bracket
Nyliner Bearing
Coil Assembly
Mach. Screw, 6-32 x W'
Mach. Screw, 10-32 x 3/8"
Lockwasher #10 Split
Coil Tubing
Diverter Plunger Assembly
Master Spring
Drive Arm Assembly
Set Screw, 10-32 x W'
