A-15849-R-2
Flipper Assembly
..•.•...-----------_<,
.................•...•..
------
.•.....•............•..
Item Part Number
Description
Item Part Number
Description
1 B-13104-R
Flipper Base Assembly, Right
18 A-15848-R
Crank Link Assembly, Right
2 SW-1A-194
Switch Assembly
a) A-1705D-R
Flipper Crank Assembly, Right
3 4701-00002-00
Lockwasher #6 Split
b) A-15847
Flipper Link Assembly
4 4105-01019-10
Sh. Metal Screw, #5 x 5/8
n
c)
02-4676
Link Spacer Bushing
5 4008-01079-05
Mach. Screw, 8-32 x 5/16"
d) 4010-01086-14
Cap Screw, 10-32 x 7/8
n
6 4701-00003-00
Lockwasher #8 Split
e) 4700-00023-00
Flat Washer, 5/8 x 13/64 x 16ga.
7 01-9375
Switch Mounting Bracket
f)
4701-00004-00
Lockwasher #10 Split
8 20-6516
Speednut, Tinnerman
g) 4410-01132-00
Nut 10-32 ESN
9 4010-01066-06
Cap Screw, 10-32 x 3/8
n
19 23-6577
Bumper Plug, 5/8"
10 4701-00004-00
Lockwasher #10 Split
20 03-7568
Flipper Bushing
11 A-12360
Flipper Stop Assembly
12 FL-11629
Flipper Coil, Blue
a)
03-7066-5
Coil Tubing
Associated Parts:
13 01-7695
Solenoid Bracket
(Not Shown)
14 4006-01017-04
Mach. Screw, 6-32 x 1/4"
15 10-364
Spring
21 23-6695
Flipper Rubber Ring
16 4006-01005-06
Mach. Screw, 6-32 x 3/8
n
22 20-10110-5
Flipper w/Shaft
17 4406-01117-00
Nut 6-32 Hex.
Flipper Notes ...
1. Each Flipper Assembly is mounted beneath the playfield, in conjuction with the Plastic Flipper
&
Shaft, and Flipper Rubber on the upper side of the playfield.
2. With the flipper, in the non-activated position, the E.O.S. Switch contacts must have
a
gap of .062
(:t:.
015) inch. When flipper is activated switch must close.
3. Any adjustment of the E.O.S. switch must be made at
a
minimum distance of 0.25 inch from the switch body.
4. Longer blade of E.O.S. switch must be made straight.
Gap adjustment is done by adjusting shorter blade.
5. All moving elements of the assembly must operate freely without any evidence of binding.
6. Apply Loctite'"
245
when reataching screws to the Flipper Stop Assembly, the Solenoid Bracke~ and the Flipper Bushing.
2-17
