Kicker Assemblies - cont'd
rG
/
/
Kicker Assembly
A·20450
Item Part Number
Description
1 02-3407
Solenoid Plunger
2 A-5652-1
Kicker Crank Assembly
3 A-11396
Kicker Mounting Bracket
4 12-6227
Hairpin Clip
5 4700-00030-00 Flat Washer,
9/32xl/2x22ga.
6 03-8085
Armature Link
7 20-8716-5
Roll Pin, 1/8 x
7/16"
Associated Assembly:
8 A-20451
Coil & Bracket Assembly
a) A-17808
Bracket & Slop Assembly
b) 01-8-508-S Co!! Retaining Bracket
c) 4006-01017-06 Mach. Screw, 6-32 x 3/8"
d) 4406-01119-00 Nul, 6-32 ESN
e) AE-28-1500 Coil Assembly
f) 03-7066
Coil Tubing
9 10-128
Spring
Bottom Arch Kicker Assembly
B-11873
Item Part No.
Description
1.
A-6306-2
2.
01-11273
3.
Ot-8-508-T
4.
10-135
5.
23-6420
6.
AE-23-800
7.
03-7067-5
8.
4008-01017-05
9.
03-8523
Bell Armature Assembly
Mtg. Kicker Bracket Assembly
Solenoid Bracket
Solenoid Spring
Rubber Grommet
Coli Assembly
Coil Tubing
Mach. Screw, #8-32 x
5116'
Insulator
(jJafPLt
/MIDWAY
5-28c
