Item Part Number
Description
Kicker Assemblies - confd
Shooter Lane Auto Kicker Ass'y
A-20439
1 04-10210 .3 KickerCrankAssembly
2 04-10211 .3 Co iI Mount ingBracket
3 A-12390
FlipperStop BracketAssemb ly
4 4010-01066-06 Cap Screw,#10
x
3/8"
5 4701-00004-00 LockWasher#10Sp lit
6 AE-23-800 Coil Assembly
7 03-7066
Coil Tub ing
8 01-8413
Coil MountingBracket
9 10-128
Spr ing
10 A-15847
Flipper LinkAssembly
11 4700-00 104-00 FlatWashe r,
23/64
x
1/2
x
16ga ,
12 12-6227
Hai rpinClip
13 4006 -01003-05 Mach. Screw,6-32
x
5/16 "
14 01-8600
Insulator
* 15 5647 -12693-62 Mini-MicroSwitch
16 4002 -01105-08 Mach.Screw ,#2-56
x
1/2"
17 H-16437
Cab le
18 5070 -09054-00 DiodelN4004
19 H-19523
Cable
*Reworked to create 5647-12693 -65(See p. 4-24e).
5-28b
