Page 397 - Williams BLUE Parts Catalog 16-9064-B

Description
Ball Kicker Arm and Kickblg Arm Assemblies - cont'd
Klckbig Arm Assembly
B a 11395 B a 11395-1
Clip, Hair Pin
Kickbig Arm Assembly
(w/Metal Striker)
Plunger Assembly
Coil Plunger
RoIIP!n
Armature Unk
Washer
Mounting Bracket
Coil Mounting Bracket
Machine Screw
Coil Bracket
Elastic Stop Nut
Coil Assembly
Spring
Coil Sleeve Tubing
Kickbig Arm Assembly Kicker Arm Assembly
8-12265 8-12283
Item Part No. Description Item Part No. Description
1 12-6227 Clip, Hair Pin 1 12-6227 Clip. Hair Pin
2 A-5652-1 Klckblg Arm Assembly 2 A-7986 Kicker Arm Assembly
(wlMetal Striker) (w/Nylon Striker)
3 A-S050 Plunger Assembly 3 A-8050-1 Plunger Assembly
a) 02-3407 Coli Plunger a) 02-3407-2 Coil Plunger
b) 20-8716-5 RoUPin b) 20=8716-5 RoUPin
c) 03-8085 Armature Link c) 03-8085 Armature link
4 4700-00030-00 Washer 4 4700-00073-00 Washer
5 B-11396 Mounting Bracket 5 A-5653 Mounting Bracket
6 8-7572-1 Coil Mounting Bracket 6 8-7572-1 Coil Mounting Bracket
7 4006-01017 -06 Machine Screw 7 4006-01017-06 Machine Screw
8 01·8-508-S Coli Bracket B 01-8-508·S Coil Bracket
9 4406-01119-00 Elastic Stop Nut 9 4406-01119-00 Elastic Stop Nut
10 See chart p. 5·10b Coil Assembly 10 See chart p. 5-10b Coil Assembly
11 10·128 Spring 11 10-128 Spring
12 03-7066 Coil Sleeve Tubing 12 03-7066 Coil Sleeve Tubing
Note: See drawing on 5-100.
lIem Part No.
1
2
12-6227
A-5652-1
3
a)
b)
c)
4
5
6
7
8
9
10
11
12
A-5103
02-2364
20-8716-5
03-8085
4700-00030-00
8-11052
8-7572-1
4006-01 017-06
01-8-508-5
4406-01119·00
See chart p. 5-10b
10-128
03·7066
ELECTRONICS GAMES. INC. 5-10e
