Page 396 - Williams BLUE Parts Catalog 16-9064-B

Ball Kicker Arm and Kickbig Arm Assemblies - cont'd
Kickbig Arm Assembly
B·11395 8·11395 ·1
Item Part No. Description
1 12-6227 Clip, Hair Pin
2 A-5652-1 Kickbig Arm Assembly
(w/Metal Striker)
3 A-5103 Plunger Assembly
a) 02-2364 Coil Plunger
b) 20-8716-5 Roll Pin
c) 03-8085 Armature Link
4 4700-00030-00 Washer
5 B-11052 Mounting Bracket
6 8-7572-1 Coil Mounting Bracket
7 4006-01017-06 Machine Screw
8 01-8-508-S Coil Bracket
9 4406-01119-00 Elastic Stop Nut
10 See chart p. 5-10b Coil Assembly
11 10-128 Spring
12 03-7066 Coil Sleeve Tubing
Kickbig Arm Assembly Kicker Arm Assembly
8-12265 8·12283
Item Part No. Description Item Part No. Description
1 12-6227 Clip, Hair Pin 1 12-6227 Clip, Hair Pin
2 A-5652-1 Kickbig Arm Assembly 2 A-7986 Kicker Arm Assembly
(w/Metal Striker) (wINy Ion Striker)
3 A-8050 Plunger Assembly 3 A-8050-1 Plunger Assembly
a) 02-3407 Coil Plunger a) 02-3407-2 Coil Plunger
b) 20-8716-5 Roll Pin b) 20-8716-5 Roll Pin
c) 03-8085 Armature Link c) 03-8085 Armature link
4 4700-00030-00 Washer 4 4700-00073-00 Washer
5 B-11396 Mounting Bracket 5 A-5653 Mounting Bracket
6 B-7572-1 Coil Mounting Bracket 6 8-7572-1 Coil Mounting Bracket
7 4006-01017-06 Machine Screw 7 4006-01017-06 Machine Screw
8 01-8-508-S Coil Bracket 8 01-8-508-S Coil Bracket
9 4406-01119-00 Elastic Stop Nut 9 4406-01119-00 Elastic Stop Nul
10 See chart p. 5-1Ob Coil Assembly 10 See chart p. 5-10b Coil Assembly
11 10-128 Spring 11 10-128 Spring
12 03-7066 Coil Sleeve Tubing 12 03-7066 Coil Sleeve Tubing
5-1Od ELECTRONICS GAMES. INC.
