Page 226 - Williams BLUE Parts Catalog 16-9064-B

JOKERZI (567)
Ball Guide and Ramp Locations
Item Part No. Description
1 B-12363-l Left Flipper Return Frame
2 A-12339 Ball Guide Assembly
3 A-12208 Ball Guide Assembly
4 0-12275 Center Ramp Assembly
5 0-12277 Left Ramp Assembly
6 B-12340 Ball Guide Assembly
7 0-12205 Ball Guide Assembly
8 8-12207 Ball Guide Assembly
9 8-12206 Ball Guide Assembly
10 8-12486 Ramp Deflector Assembly
11 0-12276 Right Ramp Assembly
12 B-12278 Lifting Ramp
13 B-12363-R Right Flipper Return Frame
14 8-8623 Ball Guide and 8affle
15 01-3569-1 Ball Return Runway
16 C-8235 Ball Runway
17 31-1008-567 Screened Bottom Arch
3-88
