B. Stri ng Catch er-(Repl aces the kicker in some model s)
1 .
The
"V"
in the string catc her should be assemble d even wit h the bottom of the
kicker opening.
2. On Nickel and Quarter Acceptors , the string catcher is moved as far to the right
as it will go.
3. On Dime Acce ptors, the string catcher is move d as far to the left as it wi ll go.
MAINTENANCE
Depen ding upon the environmen t in wh ich the Accep tor is used, per iodic preventative main-
tenan ce shou ld be performed .
The ma inplate may be cleane d with any hous eho ld clea nser. Thorough rinsing and drying
are necessa ry to remove depos its and /or film.
Remove an filings from the mag net by guiding an ice pick, awl, or the poi nt of a screw
driver along the edges of the magnet . You wi ll notice the filings will cling to the poi nt of the too l.
Remove the tran sfer crad les and undersi ze levers and clean the bushi ngs. A pipe cleaner
makes a good bushing cleaner. Also clean the pivot pin. Apply powde red graphi te or pencil lead
sparingly to the pivot pin and bushing and reassemble.
On Nickel units make certain all fore ign matter is removed from the bounce teste r. Also
make certain the bounce tester fas tening screw s are tigh t.
In the event the recom mended adjustment and mainte nance procedu res do not render your
"Series 50" Acceptor serviceable, chec k for worn or damaged par ts and rep lace as neces sary.
For service assistance or sales requi rements, contact our branch office in your area.
PARTS AND SERVICES AVAILABLE IN THE FOLLOWING CITIES
ATLANTA, GEORGIA
RIVER GROVE, I.LUNOIS
CINCINNATI
24, OHIO
ARLINGTON, TEXAS
HONOLULU, HAWAII
HOUSTON 6, TEXAS
LOS ANGELES 7, CALIF.
LONG ISLAND CITY, N. Y.
PHILADELPH IA
PITTSBURGH 14, Pl..
BURLINGAME, CAUF.
ST. LOUIS 10, MO.
WEST HILL, ONTARIO
658 ELEVENTH ST. N.W.
8490 W. GRAND AVE.
1345 NORTH BEND
1823 WILL SCARLET RD.
2850 KAIHIKAPU ST.
2183 PORTSMOUTH AVE.
3605 S, BROADWAY
23-10 44TH DRIVE
(CONTACT NEW YORK BRANCH)
2442 EAST ST.
877 COWAN ROAD
1711 HEREFORD ST.
528 ROUGE
HILL
DR., WEST ROUGE,
875-8049
453-8221
542-0505
275-2164
58-7115
526-4601
232-0286
361-1451
322-4111
697-7416
664-5550
282-0597
171 1 HEREFORD S T . ' SA I NT L O UI S 10 , MO
3-( ; 4 - 15 00
