Kicker Arm and Kickbig Arm Assemblies - cont'd
Klckblg Arm Assembly
Klckblg Arm Assemblies
8
R
11051-R
8-11395
(Right)
8-11395-1
(Left)
Item Part Number
Description
Item Part Number
Description
1 12-6227
Hairpin Clip
12-6227
Hairpin Clip
2 A-5652-1
Kickbig Arm Assembly
2 A-5652-1
Kickbig Arm Assembly
(w/Metal Striker)
(w/Metal Striker)
3 A-5103
Plunger Assembly
3 A-5103
Plunger Assembly
4 4·700-00030-00
FW .265 x .500 x .067
4 4700-00030-00
FW .265 x .500 x .067
5 B-11502
Mounting Bracket
5 B-11502
MOLlntingBracket
6 B-7572-1
Coil Mounting Bracket
6 B-7572-1
Coil Mounting Bracket
7 4006-01 017-06
MS #6-32x318 P-RH
7 4006-0 1017-06
MS
#6-32x3/8
P-RH
8 01-8-508-S
Coil Bracket
8
01-8-508-S
Coil Bracket
9 4406-01119-00
Elastic Slop Nut
9 4406-01119-00
Elastic Stop Nut
10 See chart p. 5-26 Coil Assembly
10 See chart p. 5-26 Coil Assembly
11 10-128
Spring
11 10-128
Spring
12 03-7066
Coil Sleeve Tubing
12 03-7066
Coil Sleeve Tubing
Kicker Arm Assembly
8-12665
Item Part Number
Description
12-6227
Hairpin Clip
2 A-12664
Kicker Arm Assembly
(w/Metal Striker)
3 A-5103
Plunger Assembly
4 4700-00030-00
FW .265 x .500 x .067
5 A-5653
Mounting Bracket
6 B-7572-1
Coil Mounting Bracket
7 4006-01017 -06
MS #6-32x3/8 P-RH
8
01-8-508-$
Coil Retaining Bracket
9 4406-0111 9-00
Elastic Stop Nut
10
See chart p. 5-26 Coil Assembly
11
10-128
Spring
12 03-7066
Coil Sleeve Tubing
5-24
