Kicker Arm and Kickbig Arm Assemblies - cont'd
y.
o
10
Slingshot Kicker
Assemblies
A365~0521 0-0001
C-12873
Item Part Number
Description
Item Part Number
Description
1 A967 -00011-0000
Core Plug & Brkt Assy.
A-12951
Core Plug
&
Brkt Assy.
2 A365-08700-0003
Coil
&
Tubing Assy.
2 AE-26-1500
Coil
&
Tubing Assy.
3 0017-00104-0073
Spring Washer
3 4705-0002-00
Spring Washer
1/2"
4 0360-00316-00XF
Coil Bracket
4 01-9277
Coil Bracket
5 0010-00274-0212
Compression Spring
5 10-409
Compression Spring
6 0967 -00701-00XF
Plunger
6
02-4389
Coil Plunger
7 0017-00100-0115
Retaining Ring
7 20-9613-14
Reinforced "E" Ring
8 0967 -00901-0000
Slingshot Kicker Arm
8 03-8306
Kicker Arm
9
20-8790-5
Snap-In Nyliner
9
20-8790-5
Nylined Bearing
10 0967-00130-00XF
Slingshot MIg. Bracket
10 01-9288
Slingshot MIg. Bracket
11
0017-00101-0161
#8-32 x
1/4
P-PH
11 4008-0101 5-08
IT
8-32x
1/4
PH
@af!tt/MIDWAY
5-23
