Drop Target Assemblies -
contd
3-Bank Drop Targets
C-11223-1
Item Part No.
Description
Item Part No.
Description
03-8036
Target Blade, Plain
12 AE-26·1200
Coil Assembly
2 B-13271
3-Bank Mtg. Bracket
13 01-8413
Coil Mounting Bracket
3 10-364
Retractor Spring
14 A-11389
Plunger/Reset Plate Asy.
4 (See note)
Oplo PCB Assembly
a)
02-3972-1
Plunger
5 20-8712-18
Retaining Clip, 3/16"
b)
01-8408
Reset Plate
6 20-8712-25
Retaining Clip, 1/4-
c)
4410-01132-00
Nut, 10-32 ESNA
7 10-392
Compression Spring
15 03-7066-4
Coil Tubing
8 Not used
16 4700-00016-00
Flat Wa.sher, 3/16"
9 Not used
17 4008-01 016-10
MS #8-32 x 5/8
10 4408-01119-00
Nut, 8-32 ESNA
18 4700-00072-00
Flat Washer. 1/4"
11 A-11397
Stop Bracket
19 23-6626
Rubber Grommet
Note: C-12559, 3-Bank Oplo PCB used on Transporter (2006).
C-13205, 3-Bank Oplo PCB used on Elvira (2011).
C-11223-3
(Parts listed replace same items of C-11223-1)
C-11223-4
(Parts listed replace same items of C-11223-1)
Ilem Part No.
Description
Item
Part No.
Description
03-8033
4 C-13205-1
Flush Target
Opto PCB Assembly
Oplo PCB Assembly
4 C-13205-1
