Page 193 - BallyMidway YELLOW Parts Catalog 16-9147-B

SEO Version

Ball Guide and Ramp Locations
(2006)
o
0 ° 0
<> 00 <>
14
Item Part No.
Description
1 31-1008-2006
Screened Bottom Arch
2 8-12673-l
Left Ball Return Frame
3 8-12629
Ball Guide Assembly
4 C-12569
Lift Ramp Assembly
5
8-12572
Inner Ba!! Guide Asy.
6 8-12574
Ball Guide Assembly
7 0-12620
Ramp Switch Assembly
8
B-12614
Inner lane Ball Guide Asy.
9 01-9153
Ball Stop Deflector
10 0-12.573
Outer Bali Guide Assembly
11 B-12575
Ball Guide Assembly
12
B-12673-R
Right Ball Return Frame
Under Bottom Arch:
13 B-8623
Ball Guide
&
Baffle Assy.
14 01-3569-1
Ball Return Runway
15 C-8235
Ball Runway Assembly
