Page 192 - BallyMidway YELLOW Parts Catalog 16-9147-B

(2003)
Ball Guide and Ramp Locations
Item Part No. Description
1 31-1008-2003 Screened Bottom Arch
2 B-13259 Left Flipper Return Frame
3 B-13292 Ball Guide Assembly
4 8-13294 Ball Guide Assembly
5 0-13262 Left Ramp Assembly
6 D-13260 Right Ramp Assembly
7 C-13295 Ball Guide Assembly
8 A-13290 Ball Guide Assembly
9 A-13291 Ball Guide Assembly
10 01-9464 Deflector (Eject)
11 D-13296 Ball Guide Assembly
12 0-13285 BoUrn Ramp Asy. (Under Plfd)
13 D-13261 Center Ramp Assembly
14 B-13293 Ball Guide Assembly
ri 15 C-13297 Ball Guide Assembly
0 ! Under Bottom Arch:
16 8-8623 Ball Guide & Baffle Assy.
17 01-3569-1 Ball Return Runway
18 C-8235 Ball Runway Assembly
