TOP PLAYFIElO ASSEMBLY W/O PLASTICS - PARTS LIST, CONT"D.PART NO. AE14-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
39 0360-D0147-00XF BRKT: BALL STOP
40 0360-00174-00XF BALL RUNWAY
41 0360-00175-5300 WIRE FORM: BALL GUIDE 2-3/8" (2 REQ'D.)
42 0360-00188-0000 GUIDE: BALL RETURN
43 0360-00322-0000 PROTECTIVE ANGLE
44 0360-00732-00XF POST: BUMPER #10 X 7 WOOD SCREW (6 REQID.)
45 0360-00733-00XF POST: BUMPER (NICKEL) (9 REQ'O.)
46 0360-00738-01XF STUD: #6 X 1-11/16" (8 REQ I'D.)
47 0360-00738-02XF STUD: #6 X 1-1/2" WOOD SCREW (COPPER) (5 REQ'D.)-
48 0365-00151-1750 WIREFORM: BALL GUIDE 1-3/4" (3 REQ 10. )
49 0365-00700-00XF POST: BUMPER #10/32 X 7 (3 REQ'D. )
50 0371-00129-00XF CHANNEL: BALL-REAR
51 0371-00130-0000 RAIL: TOP PLAY-ARCH (WIRE .187)
52 0391-00916-0000 GATE BRACKET (2 REQ'D.)
53 0967-00107-00XF SHOOTER LAN.E HOOD
54 0967-00127-00XF BAL-CHANNEL: FRONT
55 0967-00707-01XF STUD: #6-32 X 1-11/16" (6 REQ ID. )
1.8
